| 1. |
845-8016
|
[14] |
BOLT,Hvy Hex, M8 x 16mm, Cl 8.8
|
CAS
|
| 4. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Seal, Order A77790 or A77808
|
| 5. |
J941786
|
[1] |
CARRIER
|
CAS
|
| 6. |
J938077
|
[5] |
LOCK NUT
|
CAS
M6 Superseded by part number: 87493304
|
| 7. |
J926863
|
[11] |
FLANGE BOLT
|
CAS
Hex Flange, 8 - 1.25 X 50 MM, Class 10.9
|
| 8. |
J943885
|
[3] |
BOLT
|
CAS
M8 x 40
|
| 9. |
J926846
|
[3] |
FLANGE BOLT
|
CAS
Hex Flange, 8 - 1.25 X 20 MM, Class 10.9
|
| 11. |
J944293
|
[1] |
GASKET,1.01mm Thk
|
CAS
|
| 12. |
87349295
|
[1] |
HOUSING
|
CAS
Superseded by part number: 84337941
|
| 13. |
87350310
|
[1] |
COVER
|
CAS
|
| 14. |
J940245
|
[1] |
GASKET,1.27mm Thk
|
CAS
Superseded by part number: J940245AM
|
| 15. |
J940246
|
[1] |
COVER
|
CAS
Accessory Drive
|
| 16. |
854-12025
|
[2] |
BOLT,Hvy Hex, M12 x 25mm, Cl 10.9
|
CAS
Superseded by part number: 86624962
|
| 17. |
A77790
|
[1] |
SEAL KIT
|
CAS
Crankshaft, Front, Inc. 18 - 21
|
| 21. |
J918113
|
[1] |
SHIELD,74.73mm ID x 91.7mm OD x 6mm Thk
|
CAS
|
| 22. |
A77808
|
[1] |
SERVICE KIT
|
CAS
Crankshaft, Front, Inc. 23 - 26 Superseded by part number: A77808AM
|
| 26. |
J924987
|
[1] |
SHIELD,77.14mm ID x 89.38mm OD x 6.35mm Thk
|
CAS
|
| 27. |
J920706
|
[1] |
PLUG
|
CAS
(Not Shown)
|
| 28. |
217-438
|
[2] |
PLUG,Hex Soc, 1/2" - 14 NPTF
|
CAS
(Not Shown) Superseded by part number: 87034671
|
| 29. |
263136
|
[1] |
MAGNETIC PLUG,Sq. Soc, 3/4"-14 NPTF
|
NH
PLUG, MAGNETIC (Not Shown)
|
| 34. |
854-12030
|
[2] |
BOLT,Hvy Hex, M12 x 30mm, Cl 10.9
|
CAS
|
| 35. |
87358314
|
[1] |
3 WAY CONNECTION
|
FAR
CONNECTION Oil Drain
|
| 36. |
J906696
|
[1] |
SEAL,41mm ID x 43mm OD x 2.5mm H
|
CAS
|
| 37. |
J921816
|
[1] |
SPECIAL BOLT
|
CAS
|
| 38. |
J943408
|
[1] |
SPACER
|
CAS
|
| 39. |
A77695
|
[1] |
MOUNTING CLIP
|
CAS
|
| 40. |
J914738
|
[1] |
TUBE,32 mm ID x 38 mm OD x 138 mm L
|
CAS
Oil Fill Extension
|
| 41. |
J914136
|
[1] |
CAP
|
CAS
|
| 42. |
J936876
|
[2] |
SEALING RING,30mm ID x 48mm OD x 2.8mm Thk
|
RAC
|
| 43. |
9804276
|
[1] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 44. |
J921644
|
[1] |
ADAPTER
|
CAS
Oil Filter
|
| 45. |
J903475
|
[1] |
SEALING RING,72.39mm ID x 90.39mm OD x 9mm Thk
|
CAS
Superseded by part number: J903475AM
|
