凯斯零件查询(FLX3020) - FLOATER (6/06-1/12) (03-02) - PUMP, FUEL TRANSFER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
483 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87346904
|
[1] |
CHECK VALVE
|
CAS
|
| 2. |
87346902
|
[1] |
FUEL TUBE,0.315" OD
|
CAS
Fuel Supply
|
| 3. |
87346936
|
[1] |
ADAPTER
|
CAS
|
| 4. |
87346600
|
[6] |
SEALING WASHER,11.71mm ID x 19.3mm OD x 1.27mm Thk
|
CAS
|
| 5. |
J903035
|
[2] |
BANJO BOLT
|
CAS
|
| 6. |
845-6015
|
[4] |
BOLT,Hvy Hex, M6 x 15mm, Cl 8.8
|
CAS
Superseded by part number: 87015915
|
| 7. |
87346733
|
[2] |
BRACKET
|
CAS
|
| 8. |
87346917
|
[2] |
ISOLATOR
|
CAS
|
| 9. |
87346909
|
[1] |
FUEL PUMP
|
CAS
Superseded by part number: 84298016
|
| 10. |
87346734
|
[1] |
FUEL TUBE
|
CAS
Fuel Supply
|
| 11. |
87417767
|
[2] |
SEALING WASHER,13.67mm ID x 22.35mm OD x 1.27mm Thk
|
BRR
|
| 12. |
87339066
|
[1] |
FUEL TUBE,0.63mm OD
|
CAS
|
| 13. |
87339057
|
[1] |
BRACKET
|
CAS
|
| 14. |
J925883
|
[1] |
FLANGE BOLT,Hex, M8 x 16mm, Cl 10.9
|
CAS
Superseded by part number: J924962
|
| 15. |
87339061
|
[1] |
FUEL TUBE,0.63mm OD
|
CAS
|
