神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (01-003) - UPPER FRAME ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
982 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LP52FU0004D1 | [1] | UPPER FRAME ASSY | |
| 1. | LP52FU1021P1 | [1] | BRACKET | |
| 2. | LP52FU1022P1 | [1] | BRACKET | |
| 3. | LP52FU1019P1 | [1] | BRACKET | |
| 4. | 2418T22233 | [1] | PLATE | |
| 5. | 2416T24911 | [1] | BLOCK, TAPPED | |
| 6. | LP52FU1023P1 | [1] | BRACKET | |
| . . | LP52FU0004D2 | [1] | FRAME, UPP | |
| . . | LP52FU0004D3 | [1] | FRAME, UPP | |
| 7. | 2416T20689D2 | [1] | U-BRACKET | KOB |
| . . | LP52FU0004D4 | [1] | FRAME, UPP | |
