神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (01-005) - REDUCTION UNIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
148 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J11681F3 | [1] | GEAR REDUCTION UNIT | KOB |
| 1. | 2410N523 | [1] | ROLLER SHAFT | KOB |
| 2. | 2418T16145 | [1] | SLEEVE | KOBSLEEVE |
| 3. | ZD11G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 7. | R25P0047D7 | [1] | BALL BEARING | KOB |
| 8. | 2414J1739 | [1] | HOUSING | KOB |
| 9. | 2418T16146 | [1] | SPACER | KOB |
| 10. | 25Z627D12 | [1] | BALL BEARING | KOB |
| 11. | ZR16X07000 | [1] | RING | KOBSNAP |
| 12. | 2418T5627 | [2] | SPACER | KOB |
| 13. | 2413J374 | [1] | SPIDER | KOBSPIDER |
| 14. | 2401P1294 | [1] | SUN GEAR | KOB |
| 15. | 2401J148 | [1] | GEAR | KOB |
| 17. | 2413N448F1 | [1] | DIFF. SPIDER | KOB |
| 18. | 2401P1116 | [1] | SUN GEAR | KOB |
| 19. | 2401P1293 | [4] | PINION | KOB |
| 21. | 2410T350 | [4] | SHAFT | KOB |
| 22. | 2418T20384 | [8] | THRUST WASHER | KOB |
| 23. | ZP26D08025 | [4] | PIN | KOBRoll -- OD 08 x 25mm Long |
| 24. | 2425Z780 | [4] | NEEDLE BEARING | KOBBEARING |
| 25. | 2401P1046 | [4] | PINION | KOB |
| 26. | ZR16X03200 | [4] | LOCKING RING | KOBSNAP |
| 27. | ZE82T12000 | [1] | PLUG | KOB3/4" PT |
| 28. | ZS23C10030 | [12] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 29. | ZS23C12110 | [4] | SCREW,Hex Socket Head, M12 x 110mm | KOBM12x1.75x110mm Superseded by part number: ZS28C12110 |
| 30. | 2418T16143 | [8] | WASHER | KOBTHRUST |
| 31. | 2418R550 | [1] | OIL SEAL | KOB |
| 32. | 2418P25236 | [1] | RETAINER | KOB |
| 33. | 2418T22955 | [1] | SPACER | KOB |
| 34. | 2425R225 | [8] | NEEDLE BEARING | KOBBEARING, NEEDLE |
