神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (02-012) - SEAT ASSEMBLY, P/N 24100J17304F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
930 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YW25MU0001F1 | [1] | SEAT | KOBASSY, INCL 1 - 13 |
| 1. | YN25MU0001S001 | [1] | SEAT | KOBACCESSORY SEAT ASSY |
| 2. | YN25MU0001S002 | [1] | BACKREST COVER | KOBBACK COVER |
| 3. | YN25MU0001S003 | [1] | SEAT CUSHION | KOBBACK FORM |
| 4. | YN25MU0001S004 | [1] | SEAT COVER | KOBSEAT Superseded by part number: YN25M00008S004 |
| 5. | 2448U246S7 | [1] | SEAT CUSHION | KOBFORM |
| 6. | YN25MU0001S006 | [1] | FRAME | KOB |
| 7. | YN25MU0001S007 | [1] | CABLE | KOBADJUSTMENT Superseded by part number: GG25M00001S007 |
| 8. | YW25MU0001S008 | [1] | HANDLE | KOB |
| 9. | YW25MU0001S009 | [1] | BRACKET | KOB |
| 10. | YW25MU0001S010 | [1] | CROSSRAIL | KOB |
| 11. | YN25MU0001S017 | [1] | SUPPORT | KOBHEAD REST |
| 12. | YN25MU0001S011 | [1] | ARMREST | KOBRH |
| 13. | YN25MU0001S010 | [1] | ARMREST | KOBLH |
