神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (03-010) - CONTROL LINES, REMOTE (DOZER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
130 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J17516F1 | [1] | CONTROL LINES, REMOTE (DOZER) | |
| 1. | ZW11X20000 | [1] | WASHER | KOB(M20) |
| 2. | ZH32X04000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 3. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 4. | LE68H01017P1 | [1] | SUPPORT | KOB |
| 5. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 6. | ZP15D05040 | [1] | SPLIT PIN | SPLIT PIN |
| 7. | LE68H01021P1 | [1] | PIN | KOB |
| 8. | 2444Z2359 | [1] | TEE | KOB3/8" PT (Incls. O-Ring ZD12P01400) |
| 9. | 2436U1314F3 | [1] | SOLENOID VALVE | KOBASSY Superseded by part number: YA35V00009F1 |
| 10. | HX21E04080DX | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2420R349D080 |
| 11. | HX21E04250DX | [1] | FLEXIBLE HOSE | KOB |
| 12. | 2444R1120D060 | [1] | HOSE | KOB600mm Long (23-5/8 in) |
| 13. | 2444R1119D050 | [1] | HOSE | KOB500mm Long (19-11/16 in) |
| 14. | 2444Z3841 | [1] | TEE | KOB |
| 15. | ZS13C06012 | [2] | SCREW | KOBM06x1.0x12mm |
| 16. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 17. | ZS13C08020 | [4] | SCREW | KOBM08x1.25x20mm Superseded by part number: ZS18C08020 |
| 18. | LE68H01018F1 | [1] | LEVER | KOB |
| 19. | 2406R252D2 | [1] | GRIP | KOB |
| 20. | 2420Z1232 | [1] | NUT | KOBM12x1.25mm |
| 21. | 2406R223D9 | [1] | FLEXIBLE CONTROL | KOB |
| 22. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 23. | 2419R9D4 | [1] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
| 24. | ZW22X08000 | [4] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 25. | ZN13C08007 | [1] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 26. | 2420Z681 | [1] | ROD | KOBEND |
| 27. | 2420T6557 | [1] | STUD | KOB |
| 28. | 2406T3171 | [1] | LEVER & PIN ASSY | KOB |
| 28-3. | 2405R61D12 | [2] | BUSHING | |
| 29. | 2419T6613 | [1] | PIN | |
| 30. | ZP26D03028 | [1] | PIN | KOBSPRING |
| 31. | 2416T24942 | [1] | BRACKET | |
| 32. | ZP45X10027 | [2] | PIN | KOB |
| 33. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 34. | 2419R9D3 | [2] | PIN | KOBHair -- OD 10mm x 32.6mm Long |
| 35. | 2412T921 | [1] | FORK | KOB |
| 36. | 2412T922 | [1] | END | KOB |
| 37. | 2406T1672 | [1] | YOKE | KOB Superseded by part number: 2406T2278 |
| 38. | 2419T3784D1 | [1] | PIN | KOB |
| 39. | 2444Z3834 | [1] | TEE | KOB |
