| . . | 24100J17621F1 | [1] | CONTROL LINES, REMOTE (DOZER & EXTRA & BREAKER) | |
| 1. | 2436P231F1 | [3] | VALVE PRESSURE RELIE | KOB |
| 1-1. | 2436P232 | [1] | BODY, VALVE | |
| 1-2. | 2436T305 | [1] | VALVE | |
| 1-3. | 2418T8945D3 | [1] | SPACER ID 30 x OD 44 x Th 3.2mm | SPACER ID 30 x OD 44 x Th 3.2mm |
| 1-4. | ZR16X03000 | [1] | SNAP RING | KOBSNAP |
| 1-5. | 2420Z922 | [1] | CAPSCREW | CAPSCREW |
| 1-6. | ZD11G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB(G30 1A) |
| 1-7. | ZD12G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 1-8. | ZD85G02500 | [1] | BACK-UP RING | KOBRing, Back-Up -- ID 25 x OD 30 x Th 1.25mm |
| 1-9. | ZD12G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 1-10. | ZD75G03000 | [1] | BACK-UP RING | KOB |
| 2. | 2418P24736 | [1] | PLATE | |
| 3. | ZS13C12050 | [3] | SCREW | KOBM12x1.75x50mm Superseded by part number: ZS18C12050 |
| 4. | ZS23C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
| 5. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 6. | ZW22X12000 | [3] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 7. | ZW22X08000 | [10] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 8. | 2444Z2359 | [1] | TEE | KOB3/8" PT (Incls. O-Ring ZD12P01400) |
| 9. | YR30V00004F1 | [1] | PILOT VALVE | KOB Superseded by part number: YR30V00004F2 |
| 10. | ZH32X04000 | [14] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 11. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 12. | 2444Z2336 | [2] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 13. | ZW11X20000 | [1] | WASHER | KOB(M20) |
| 14. | 2444T2592 | [2] | TEE | KOB3/8" PF - 1/4" PF (No O-Ring supplied) |
| 15. | 2444Z3834 | [1] | TEE | KOB |
| 16. | 2444Z3841 | [2] | TEE | KOB |
| 17. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 18. | LE68H01017P1 | [1] | SUPPORT | KOB |
| 19. | ZP15D05040 | [1] | SPLIT PIN | SPLIT PIN |
| 20. | ZH22X04000 | [5] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 21. | 2444Z2544 | [1] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied) |
| 22. | 2444T2524 | [1] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 23. | HX21E04270DX | [1] | HOSE | KOB Superseded by part number: 2420R349D270 |
| 24. | HX21E04180DX | [1] | HOSE | KOB Superseded by part number: 2420R349D180 |
| 25. | HX21E04230DX | [1] | FLEXIBLE HOSE | KOB |
| 26. | HX21E04200DX | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2420R349D200 |
| 27. | HX21E04140DX | [1] | FLEXIBLE HOSE | KOB |
| 28. | HX21E04050DX | [1] | HOSE | KOB |
| 29. | HX21E04080DX | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2420R349D080 |
| 30. | HX21E04150DX | [1] | FLEXIBLE HOSE | KOB |
| 31. | HX31E04050DX | [1] | FLEXIBLE HOSE | KOB |
| 32. | 2444R1119D050 | [1] | HOSE | KOB500mm Long (19-11/16 in) |
| 33. | 2444R1120D060 | [3] | HOSE | KOB600mm Long (23-5/8 in) |
| 34. | HX21E04250DX | [1] | FLEXIBLE HOSE | KOB |
| 35. | LE68H01021P1 | [1] | PIN | KOB |
| 36. | 2444R1120D130 | [1] | HOSE | HIT |
| 37. | 2444R1120D100 | [1] | HOSE | KOB1000mm Long (39-3/8 in) |
| 38. | ZS18C08020 | [6] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 39. | 2436U1314F3 | [1] | SOLENOID VALVE | KOB Superseded by part number: YA35V00009F1 |
| 40. | ZS13C06012 | [2] | SCREW | KOBM06x1.0x12mm |
| 41. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 42. | ZS13C08020 | [4] | SCREW | KOBM08x1.25x20mm Superseded by part number: ZS18C08020 |
| 43. | LE68H01018F1 | [1] | LEVER | KOB |
| 44. | 2406R252D2 | [1] | GRIP | KOB |
| 45. | 2420Z1232 | [1] | NUT | KOBM12x1.25mm |
| 46. | 2406R223D9 | [1] | FLEXIBLE CONTROL | KOBCABLE |
| 47. | ZP45X10027 | [2] | PIN | KOB |
| 48. | 2419R9D3 | [2] | PIN | KOBHair -- OD 10mm x 32.6mm Long |
| 49. | 24100P3848F1 | [1] | LOCK | KOBASSY |
| 49-1. | PY30M01003P1 | [1] | SUPPORT | KOB |
| 49-2. | 2406P5481 | [1] | LH DOOR LOCK | KOB |
| 49-3. | HP45X10022G1 | [1] | PIN | KOB Superseded by part number: PM55M01012P1 |
| 49-4. | HP26T09002G1 | [1] | SPRING | KOB |
| 49-5. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 49-6. | 2419R9D3 | [1] | PIN | KOBHair -- OD 10mm x 32.6mm Long |
| 50. | ZN13C08007 | [1] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 51. | 2420Z681 | [1] | ROD | KOBEND |
| 52. | 2420T6557 | [1] | STUD | KOB |
| 53. | 2406T3171 | [1] | LEVER & PIN ASSY | KOB |
| 54. | 2419T6613 | [1] | PIN | |
| 55. | ZP26D03028 | [1] | PIN | KOBSPRING |
| 56. | 2416T24942 | [1] | BRACKET | |
| 57. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 58. | ZW16X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 59. | HH25X04004G1 | [1] | HYD CONNECTOR | KOB(WITH FILTER) |
| 60. | 2412T921 | [1] | FORK | KOB |
| 61. | 2412T922 | [1] | END | KOB |
| 62. | 2406T1672 | [1] | YOKE | KOB Superseded by part number: 2406T2278 |
| 63. | 2419T3784D1 | [1] | PIN | KOB |
| 64. | 2419R9D4 | [1] | COTTER PIN | KOBSnap -- OD 12mm x 35.8mm Long |
| 65. | YR03M01150P1 | [1] | PEDAL | KOB |
| 66. | YR03M01134P1 | [1] | COVER | KOB |
