神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (06-002) - HARNESS ASSY (INST PANEL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
154 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J17120F1 | [1] | HARNESS ASSY (INST-PANEL) | |
| 1. | 2479U1828 | [1] | HARNESS | KOB |
| 2. | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 3. | ZW26X10000 | [7] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 4. | 2432R225D9 | [3] | CLIP | KOBClamp, Single -- ID 22 x 54mm Long Superseded by part number: ZC46X22011 |
| 5. | 2432Z290 | [1] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 7. | 2432R225D11 | [5] | CLIP | KOBClamp, Single -- ID 29 x 62.5mm Long Superseded by part number: ZC46X29011 |
| 8. | ZN18C10008 | [4] | NUT | KOBM10x1.50mm |
