凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (04-014) - HOOD MOUNTING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
606 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
142597A1
|
[4] |
STUD
|
CAS
Ball
|
| 2. |
353308
|
[8] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 3. |
86528579
|
[24] |
NUT,M8 x 1.25
|
WIN
|
| 4. |
1968168C3
|
[2] |
GAS STRUT
|
IH
hood lift
|
| 5. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 6. |
BN309485
|
[4] |
PLATE
|
BN
Top, Single, Size 2
|
| 7. |
BN314675
|
[1] |
HOOD ASSY.
|
TYR
3 Wheel, Complete
|
| 8. |
BN63711
|
[4] |
FLANGED BEARING,25.4mm ID x 28.57mm OD x 31.75mm L
|
CUR
Flange, 1"
|
| 9. |
87529240
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.13" Thk
|
BN
0.531 x 1.062 x 0.134 HTS DOR HDN
|
| 10. |
43151
|
[4] |
BOLT,Hex, M12 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 11. |
BN316679
|
[4] |
PLATE
|
BN
Hood Pivot
|
| 12. |
BN315099
|
[2] |
CABLE
|
BN
Assembly, 3/16 X 31
|
| 13. |
BN315102
|
[2] |
LINKAGE
|
BN
Hook, Hood
|
| 14. |
BN315142
|
[4] |
SCREW,Shldr, M12 x 1.75 x 53.40mm
|
BN
Shoulder, M12-1.75
|
| 15. |
BN320194
|
[1] |
HOOD
|
TYR
Weldment, Rear Pivot, Hood
|
| 16. |
BN320193
|
[1] |
PIVOT
|
BN
Weldment, Front Pivot, Hood
|
| 17. |
BN315164
|
[4] |
CLAMP
|
BN
Pair, Single, 5/8 Tube
|
| 18. |
86624185
|
[32] |
WASHER,8.8mm ID x 17.5mm OD x 2mm Thk
|
FOR
|
| 19. |
120104
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 20. |
43127
|
[8] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 21. |
120056
|
[8] |
BOLT,M6 x 1.0 x 54.15mm, Cl 8.8
|
NH
|
| 23. |
9849996
|
[4] |
CLIP
|
WIN
Retainer Ball Stud
|
| 24. |
BN320210
|
[4] |
JAM NUT
|
BN
1 1/8"-12, Jam
|
| 25. |
BN320207
|
[2] |
SPACER
|
BN
Hood Adjust, Offset
|
| 26. |
BN320209
|
[2] |
COLLAR
|
BN
Hood Adjust
|
| 27. |
BN320205
|
[4] |
ADJUSTER
|
BN
Weldment, Hood
|
| 28. |
BN320270
|
[4] |
PIVOT
|
BN
Weldment, Hood Mount
|
| 29. |
11106231
|
[8] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9
|
LEC
|
| 30. |
100037
|
[12] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 31. |
86639209
|
[8] |
BOLT,M8 x 1.25 x 40.45mm, Cl 10.9
|
FAR
|
