凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (04-015) - RADIATOR SCREEN ASSEMBLY-TOP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
807 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2294431
|
[8] |
SET SCREW,1/4" - 20
|
BN
1/4-20, FLN, SS
|
| 2. |
BN324649
|
[1] |
Screen, Top
|
|
| 3. |
BN314416
|
[1] |
Foam, Top Screen, R.H.
|
|
| 4. |
BN314417
|
[1] |
Foam, Top Screen, L.H.
|
|
| 5. |
BN314418
|
[1] |
Foam, Top Screen, Rear
|
|
| 6. |
BN50138
|
[8] |
WASHER,1/4", SS
|
BN
|
| 7. |
BN324855
|
[1] |
FOAM INSULATION
|
BN
Seal, Rear
|
| 8. |
BN324856
|
[1] |
FOAM INSULATION
|
BN
Seal, Front
|
| 9. |
BN324645
|
[1] |
FOAM INSULATION
|
BN
Seal
|
| 10. |
BN324857
|
[2] |
FOAM INSULATION
|
BN
Seal, Side
|
