神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (12-018) - VALVE ASSY CONTROL (SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
543 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U2716F1 | [1] | CONTROL VALVE | KOBVALVE ASSY,CONTROL (SWING) |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCASE |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER |
| 3. | 2436U2716S3 | [1] | COVER | KOB |
| 4. | 2436U2716S4 | [2] | GUIDE | |
| 5. | 2436U2716S5 | [1] | CAP | KOB |
| 6. | 2436U2716S6 | [1] | SPRING | KOB |
| 7. | 2436U2716S7 | [2] | O-RING | KOB |
| 8. | 2436U2716S8 | [1] | RETAINER | KOB |
| 9. | ZS23C08025 | [4] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 10. | 2436U2716S10 | [1] | CHECK VALVE | KOB |
| 11. | 2436U2716S11 | [1] | SPRING | KOB |
| 12. | 2436U2716S12 | [1] | CAP COVER | KOBPLUG |
| 13. | ZD12P02240 | [1] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 14. | ZS23C12045 | [4] | SCREW,Hex Socket Head, M12 x 45mm | KOBM12x1.75x45mm Superseded by part number: ZS28C12045 |
| 15. | 2436U1309S41 | [1] | CAP | KOBPLUG |
| 16. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 17. | 2436U2716S17 | [1] | SEAT | KOBSHUTTLE |
| 18. | 2436U2716S18 | [1] | BALL | KOB |
| 19. | 2436U2716S19 | [1] | CHECK VALVE | KOB |
| 20. | 2436U2716S20 | [1] | SPRING | KOB |
| 21. | ZD12P02100 | [1] | O-RING,2.4mm Thk x 20.8mm ID, 90 Duro | KOBO-Ring -- ID 20.80 ± 0.23 x OD 25mm |
| 22. | ZD85P02100 | [1] | RING | KOBBack-Up -- ID 21 x OD 25 x Th 1.25mm |
| 23. | 2436U2716S23 | [1] | CAP | KOBPLUG |
| 24. | ZD12P02200 | [2] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm |
| 25. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
