| . . | LP15V00001F1 | [1] | HYDRAULIC MOTOR | KOBMOTOR ASSY (PROPELLING) Superseded by part number: LP15V00001F2 |
| 1. | 2441U829S305 | [1] | HUB | KOB |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONSPINDLE |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONFLANGE |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR |
| 6. | 2441U829S6 | [1] | CLUTCH INPUT SHAFT | KOBGEAR, INPUT |
| 7. | NSS | [3] | NOT SOLD SEPARAT | CONGEAR |
| 8. | 2441U750S8 | [1] | COVER | KOB |
| 9. | 2441U829S9 | [3] | SHAFT | KOB |
| 10. | 2441U829S306 | [1] | REPAIR KIT | KOBPIECE, DISTANCE |
| 11. | 2441U750S11 | [1] | RING | KOB |
| 14. | 2441U750S14 | [3] | SEPARATOR | KOBPIECE, DISTANCE |
| 17. | 2441U750S17 | [24] | PIN | KOB |
| 19. | LP15V00001S019 | [3] | SPECIAL BOLT | KOBREAMER |
| 20. | 2441U524S20 | [3] | SNAP RING | KOB |
| 21. | 2441U750S21 | [2] | BALL BEARING | KOB |
| 22. | 2441U750S22 | [6] | ROLLER BEARING | KOB |
| 23. | 2441U750S23 | [6] | BEARING | KOBNEEDLE |
| 24. | ZR16X02800 | [1] | SNAP RING | KOB |
| 25. | ZR16X03500 | [3] | RING | KOBRetaining -- ID 32.20 x OD 35 x Th 1.6mm |
| 27. | ZD12P00800 | [3] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 28. | ZD12G29000 | [1] | O-RING,289.30mm ID x 300.70mm OD x 5.70mm | KOB |
| 29. | 2441U829S29 | [1] | O-RING | KOB |
| 30. | 2441U829S30 | [1] | O-RING | KOB |
| 31. | 2441U750S31 | [1] | SEAL | KOBSEAL, FLOATING |
| 33. | 2441U829S33 | [2] | PLUG | KOB |
| 35. | LP15V00001S035 | [12] | SCREW | KOB |
| 36. | 2441U829S36 | [12] | WASHER | KOB |
| 37. | ZP26D04014 | [1] | ROLL PIN | KOBSPRING |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONFLANGE |
| 102. | 2441U750S102 | [1] | SHAFT | KOB |
| 103. | 2441U829S103 | [1] | PLATE | KOB |
| 104. | 2441U750S104 | [1] | BLOCK | KOBCYLINDER |
| 105. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 106. | NSS | [1] | NOT SOLD SEPARAT | CONSHOE |
| 107. | LP15V00001S107 | [1] | RETAINING PLATE | KOB |
| 108. | 2441U750S108 | [1] | BALL | KOBTHRUST |
| 109. | 2441U524S109 | [1] | PLATE | KOB |
| 110. | 2441U750S110 | [2] | WASHER | KOB |
| 112. | 2441U524S112 | [1] | PISTON | KOBPISTON |
| 113. | 2441U496S39 | [10] | SPRING | KOB |
| 114. | 2441U524S114 | [1] | SPRING | KOB |
| 115. | 2441U524S115 | [2] | PLATE | KOB |
| 116. | 2441U496S42 | [2] | PLATE | KOB |
| 118. | 2441U496S44 | [1] | SPRING SEAT | KOBVALVE |
| 119. | 2441U496S45 | [1] | HYDRAULIC VALVE | KOB |
| 120. | 2441U496S46 | [1] | SPRING | KOB |
| 121. | 2441U995S121 | [1] | PLUG | KOB |
| 122. | 2441U496S53 | [1] | RING | KOB |
| 123. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 124. | 2441U496S48 | [2] | PLUG | KOB |
| 125. | 2441U496S49 | [2] | STOP | |
| 126. | 2441U496S50 | [2] | PLUG | KOB |
| 127. | 2441U496S51 | [2] | HYDRAULIC VALVE | KOB |
| 128. | 2441U496S52 | [2] | SPRING | KOB |
| 130. | 2441U496S54 | [2] | SPRING | KOB |
| 132. | 2441U750S132 | [1] | SEAL KIT | HIT Superseded by part number: Y0595100900 |
| 133. | ZD12P00900 | [1] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 135. | ZD12P14500 | [1] | O-RING | KOB |
| 138. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 139. | ZD12G17000 | [1] | O-RING,169.30mm ID x 180.70mm OD x 5.70mm | KOB |
| 140. | ZD12P00800 | [1] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 141. | 2441U829S141 | [2] | PIN | KOB |
| 142. | 2441U829S142 | [2] | PIN | KOB |
| 143. | ZS23C14040 | [9] | SCREW,Hex Socket Head, M14 x 40mm | KOBM14x2.0x40mm |
| 145. | 2441U829S145 | [1] | SNAP RING | KOBSNAP RING |
| 147. | LP15V00001S147 | [1] | BACK-UP RING | KOB |
| 148. | LP15V00001S148 | [1] | BACK-UP RING | KOB |
| 149. | LP15V00001S149 | [1] | BEARING | KOBBALL Superseded by part number: 81875518 |
| 150. | 2441U829S150 | [1] | BALL BEARING | KOBBALL Superseded by part number: 7781139 |
| 151. | 2441U829S151 | [3] | BEARING | KOB |
| 152. | 2441U829S152 | [2] | PLUG | KOB |
| 153. | 2441U829S302 | [1] | THRUST PLATE | KOBTHRUST |
| 154. | 2441U829S154 | [2] | EXPANDER | KOB |
| 155. | ZD12P03200 | [2] | O-RING | KOBID 31.70 ± 0.31 x OD 38mm |
| 156. | ZD12P02000 | [4] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 161. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 162. | NSS | [1] | NOT SOLD SEPARAT | CONSHOE |
| 167. | 2441U829S167 | [2] | BALL | KOB |
| 168. | 2441U815S26 | [2] | BALL | KOB |
| 169. | 2441U750S169 | [1] | PLATE | KOB |
| 170. | ZS23C08065 | [4] | CAP,Hex Socket Head, M8 x 65mm | KOBScrew -- M08x1.25x65mm |
| 171. | 2441U750S171 | [4] | LOCK WASHER | KOB |
| 179. | LP15V00001S179 | [1] | SPRING | KOB |
| 186. | LP15V00001S186 | [1] | SPOOL | KOB |
| 187. | 2441U829S187 | [1] | STOPPER | |
| 188. | 2441U829S188 | [1] | HYD CONNECTOR | KOB |
| 189. | 2441U829S189 | [1] | SPRING | |
| 190. | ZD12P01000 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 197. | 2441U829S304 | [1] | CAB FILTER | KOB |
| 198. | 2441U829S198 | [3] | EXPANDER | KOB |
| 199. | 2441U829S199 | [1] | PLATE | KOBNAME |
| 200. | LP22V00004F1 | [1] | VALVE | KOBBRAKE |
| . . | LP15V00001R200 | [1] | REPAIR KIT | KOBCONSIST OF REF. 10, 31 |
| . . | LP15V00001R300 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 101, 123, 152, 154,197-199 |
| . . | LP15V00001R400 | [1] | SEAL KIT | KOBCONSISTS OF REF. 27-31, 132, 133, 135, 138, 139, 147, 148, 155, 156, 190 |
| . . | 2441U829R300 | [1] | REPAIR KIT | KOBCONSISTS OF REF. 4, 5, 9, 22, 23 |
| . . | 2441U829R400 | [1] | REPAIR KIT | KOBCONSISTS OF REF 7 |
| . . | 2441U829R600 | [1] | REPAIR KIT | KOBCONSISTS OF REF 105, 106 |
| . . | 2441U829R800 | [1] | REPAIR KIT CONSISTS OF REF 161, 162 | REPAIR KIT CONSISTS OF REF 161, 162 |
