神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (12-034) - VALVE ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
556 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1310F1 | [1] | VALVE | KOBASSY |
| 101. | 2436U1310S101 | [1] | CASE | |
| 141. | 2436U1310S141 | [1] | SLEEVE | |
| 151. | 2436U1207S151 | [2] | PLUG | KOB |
| 152. | 2436U1485S552 | [1] | PLUG | KOB |
| 153. | 2441U729S151 | [2] | PLUG | |
| 161. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 162. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 163. | ZD12P02200 | [1] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm |
| 164. | ZD12P03000 | [1] | O-RING | KOBID 29.70 ± 0.29 x OD 36mm |
| 165. | ZD12P02800 | [1] | O-RING | KOBID 27.70 ± 0.27 x OD 34mm |
| 167. | ZD12P03200 | [1] | O-RING | KOBID 31.70 ± 0.31 x OD 38mm |
| 171. | ZS23C08065 | [2] | CAP,Hex Socket Head, M8 x 65mm | KOBScrew -- M08x1.25x65mm |
| 311. | 2436U1310S311 | [1] | PLUNGER | |
| 312. | 2436U1310S312 | [1] | SPOOL | |
| 321. | 2436U1207S321 | [1] | SPRING | KOB |
| 322. | 2436U1310S322 | [1] | SPRING | KOB Superseded by part number: 2436U1207S322 |
