神钢零件查询(SK130LC) - EXCAVATOR BTW YPU1001 - YPU2000 (1/98-12/98) (12-043) - VALVE ASSY PILOT (YN30V00004F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
597 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YR30V00004F1 | [1] | PILOT VALVE | KOBASSY, PILOT Superseded by part number: YR30V00004F2 |
| 1. | 2436U1142S13 | [2] | SHIM | KOB |
| 2. | 2436U1487S7 | [2] | SHIM | KOB |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 4. | NSS | [2] | NOT SOLD SEPARAT | CONSPOOL |
| 5. | 2436U1354S5 | [2] | SLEEVE | KOB |
| 6. | 2436U1354S6 | [1] | COVER | KOB |
| 7. | NSS | [2] | NOT SOLD SEPARAT | CONPUSHER |
| 8. | 2436U1354S9 | [1] | PIN | KOB |
| 9. | 2436U1354S10 | [1] | BOOT | KOB |
| 10. | 2436U1354S11 | [2] | COLLAR CLAMP | KOB |
| 11. | 2436U1354S27 | [2] | SPRING | KOB |
| 12. | YR30V00004S012 | [2] | SPRING | KOB |
| 13. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 14. | 2436U1354S8 | [1] | CAM | KOB |
| 15. | 2436U1354S25 | [2] | SHIM | KOB |
| 17. | ZS23C12020 | [1] | CAPSCREW,Hex Socket Head, M12 x 20mm | KOBSCREW M12x1.75x20mm |
| 18. | 2436U1354S15 | [2] | BOLT | KOB |
| 19. | 2436U1354S16 | [2] | WASHER | KOB |
| 20. | 2436U1354S17 | [4] | WASHER | KOB |
| 21. | 2436U1487S35 | [2] | RIVET | KOBSCREW |
| 22. | 2436U1354S19 | [2] | PIN | KOBSPRING |
| 23. | ZP15K02516 | [2] | SPLIT PIN | KOBPIN Superseded by part number: ZP15K02515 |
| 24. | NSS | [2] | NOT SOLD SEPARAT | CONBALL |
| 25. | ZD11P01000 | [2] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm |
| 26. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| . . | 2436U1354S26 | [2] | PISTON | KOB |
