神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (03-009[01]) - ARM HYDRAULIC LINES, 3.10M (10FT 2IN) (NIBBLER AND BREAKER) (OPT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
136 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM43H00003F1 | [1] | HYD LINK, ARM 3.10M(Nibbler & Breaker) | |
| D1. | YM43H01002P1 | [1] | TUBE | KOBTUBE |
| D2. | YM43H01003P1 | [1] | TUBE | KOBTUBE |
| D3. | ZX50H12160 | [2] | HYDRAULIC HOSE | KOB1600mm Long (63 in) |
| D4. | 24100P1006F1 | [2] | VALVE | KOBVALVE, STOP Superseded by part number: 24100P1006F2 |
| D4-1. | 2436P230 | [1] | VALVE BODY | KOBBODY, VALVE |
| D4-2. | 2436T304 | [1] | VALVE | KOBVALVE |
| D4-3. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| D4-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| D4-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| D4-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| D4-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| D4-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| D4-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| D4-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| D4-11. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| D5. | HG23H12012G1 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| D6. | 2432T6122 | [4] | CLAMP | KOBSingle Block -- 75x50x25mm |
| D7. | YW43H01044P1 | [2] | BRACKET | KOBBRACKET |
| D8. | ZS18C08025 | [4] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| D9. | ZS18C12045 | [4] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| D10. | ZS18C12055 | [8] | SCREW,Hex, M12 x 55mm | KOBM12x1.75x55mm |
| D11. | ZW16H08000 | [8] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| D12. | 2418T10357 | [4] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| D13. | ZW26X12000 | [12] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| D14. | ZD12A01800 | [4] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
