凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (03-002) - TRANSMISSION MOUNTING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
169 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87529240
|
[8] |
WASHER,0.53" ID x 1.06" OD x 0.13" Thk
|
BN
0.531 x 1.062 x 0.134 HTS DOR HDN
|
| 2. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 3. |
87848
|
[8] |
BOLT,Hex, 1/2" - 20 x 1", Gr 5
|
GI
|
| 4. |
11106231
|
[4] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9
|
LEC
|
| 5. |
86512555
|
[2] |
NUT,M16 x 2, Cl 10
|
FOR
|
| 6. |
BN300500
|
[5] |
WASHER,M12, 10.9
|
BN
Superseded by part number: 86625255
|
| 7. |
BN50155
|
[2] |
WASHER,17.48mm ID x 44.45mm OD x 3.05mm Thk
|
BN
5/8", G5
|
| 8. |
9706693
|
[5] |
BOLT,M12 x 60mm, Cl 8.8
|
NH
|
| 9. |
86541970
|
[2] |
BOLT,Hex, M16 x 100mm, Cl 10.9
|
WIN
|
| 10. |
BN306728
|
[2] |
ENGINE MOUNT
|
BN
|
| 11. |
BN308164
|
[2] |
WASHER
|
BN
Rebound
|
| 12. |
BN314619
|
[1] |
MOUNTING PLATE
|
BN
Transmission/Frame, RS
|
| 13. |
BN314620
|
[1] |
MOUNTING PLATE
|
BN
Transmission/Frame, CS
|
| 14. |
BN317687
|
[1] |
MOUNTING PLATE
|
BN
Weldment, Rear Transmission Mount
|
