凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (03-003) - DRIVELINE GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
530 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 2. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 3. |
BN300499
|
[8] |
WASHER,M10, 10.9
|
BN
Superseded by part number: 896-11010
|
| 4. |
BN300500
|
[4] |
WASHER,M12, 10.9
|
BN
Superseded by part number: 86625255
|
| 5. |
9706704
|
[4] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 6. |
374887
|
[2] |
BOLT,Hex, M12 x 1.75 x 100mm, Cl 8.8
|
NH
|
| 7. |
BN303064
|
[1] |
HANGER
|
BN
Driveline, 3176
|
| 7A. |
BN303065
|
[1] |
TUBE
|
BN
Driveline Bracket
|
| 7B. |
BN303066
|
[2] |
BRACKET, SUPPORTING
|
BN
Mount, Driveline Bracket
|
| 7C. |
BN303067
|
[2] |
BRACKET, SUPPORTING
|
BN
Doubler, Driveline Bracket
|
| 7D. |
BN313908
|
[1] |
DRIVE SHAFT
|
BN
Solid With Hanger
|
| 7E. |
BN2294170
|
[1] |
U-JOINT SPIDER
|
BN
5-280X (1710)
|
| 7F. |
BN307686
|
[1] |
HANGER
|
BN
Bearing (1710 HD)
|
| 7G. |
BN307687
|
[1] |
YOKE
|
BN
End (1710 HD)
|
| 7H. |
BN307688
|
[1] |
WASHER
|
BN
Superseded by part number: 76036116
|
| 7J. |
BN307689
|
[1] |
NUT
|
BN
(1710 HD)
|
| 9. |
BN302123
|
[1] |
DRIVEN SHAFT
|
BN
Driveline, 1710 Head Slip
|
