凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (01-001) - LEFT DASH ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
873 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN316978
|
[1] |
DASH PANEL
|
BN
Left
|
| 2. |
BN314887
|
[1] |
DECAL
|
BN
Left Dash
|
| 3. |
BN304524
|
[1] |
SPEEDOMETER
|
BN
3.38 X 80Mph W/OD
|
| 4. |
86636599
|
[1] |
TACHOMETER
|
PA
3.38 x 3K With Hourmeter
|
| 5. |
BN315188
|
[1] |
GAUGE
|
BN
Assembly, Oil Temp
|
| 6. |
BN2296730
|
[1] |
GAUGE
|
BN
Water Temp "Smart"
|
| 7. |
BN2296752
|
[1] |
FUEL GAUGE
|
BN
Fuel Level
|
| 8. |
BN2296753
|
[1] |
GAUGE
|
BN
Voltmeter 06355-01
|
| 9. |
BN2296754
|
[1] |
OIL PRESSURE GAUGE
|
BN
Oil Press "Smart"
|
| 10. |
BN2390774
|
[1] |
GAUGE
|
BN
Air Pressure 0-150
|
| 11. |
BN2293217
|
[1] |
BUZZER
|
BN
|
| 12. |
BN2294958
|
[1] |
SWITCH
|
BN
Windshield Wiper Superseded by part number: V91873
|
| 13. |
BN2291956
|
[2] |
SWITCH
|
BN
Cutler Hammer
|
| 14. |
BN2291214
|
[2] |
INDICATOR LIGHT
|
BN
Blue
|
| 15. |
BN2291234
|
[4] |
INDICATOR LIGHT
|
BN
Red
|
| 16. |
BN2394623
|
[1] |
PLUG
|
BN
Dash 1/2" #2643
|
| 16A. |
BN2290525
|
[1] |
FITTING
|
BN
VS68AB-4-2
|
| 18. |
BN315370
|
[2] |
INDICATOR LIGHT
|
BN
Amber
|
| 18A. |
BN314988
|
[1] |
WIRE HARNESS
|
BN
L Dash, Hyd Lite (Under Dash)
|
| 18B. |
BN314989
|
[1] |
WIRE HARNESS
|
BN
Left Dash, (B2F) (Under Dash)
|
| 18C. |
BN314991
|
[1] |
WIRE HARNESS
|
BN
Lights, (B1F) (Under Dash)
|
| 18D. |
BN314992
|
[1] |
WIRE HARNESS
|
BN
Wiper, (B8F) (Under Dash)
|
| 18E. |
BN314993
|
[1] |
WIRE HARNESS
|
BN
Left Dash, Gnd (Under Dash)
|
| 18F. |
BN314994
|
[1] |
WIRE HARNESS
|
BN
Left Dash, Lights (Under Dash)
|
| 18G. |
BN314995
|
[1] |
WIRE HARNESS
|
BN
Left Dash, W Lights (Under Dash)
|
| 18H. |
BN315207
|
[1] |
WIRE HARNESS
|
BN
Left Dash, Maint. (Under Dash)
|
| 19. |
161-115
|
[8] |
HEX SOC SCREW,Btn Hd, 1/4" - 20 x 3/4"
|
CAS
Superseded by part number: 86625197
|
