凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (01-002) - CAB ELECTRICAL GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
784 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN65223
|
[1] |
POWER SOCKET
|
BN
Outlet, 12V
|
| 1A. |
BN2404968
|
[4] |
SELF-TAP SCREW,#8 x 5/8"
|
BN
HH #8 X 5/8 Self Tapping
|
| 2. |
282775A1
|
[1] |
IGNITION SWITCH
|
CAS
With Padded Keys
|
| 3. |
BN2291152
|
[1] |
REPAIR KIT
|
BN
Low Air Pressure 326
|
| 4. |
BN310461
|
[1] |
SWITCH
|
BN
Dependent(On)-Off-(On)
|
| 5. |
BN310463
|
[1] |
SWITCH
|
BN
Dependent, On-None-On
|
| 6. |
BN302305
|
[1] |
THROTTLE
|
BN
Pedal - Engine Dependent
|
| 6A. |
BN302720
|
[1] |
PLATE
|
BN
ELEC., Throttle Pedal
|
| 6B. |
BN300363
|
[3] |
BOLT
|
BN
M6-1 X 20, HH, 8.8
|
| 6C. |
BN300428
|
[3] |
NUT
|
BN
M6-1, FLN, 8.8 Superseded by part number: 9804276
|
| 6D. |
43234
|
[3] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 10.9, Full Thd
|
NH
|
| 6E. |
BN304315
|
[3] |
NUT
|
BN
M8-1.25, FLN, 10.9 Superseded by part number: 832-46408
|
| 7. |
BN29522
|
[1] |
SWITCH
|
BN
Dimmer Floor Mount
|
| 7A. |
BN29618
|
[1] |
MOUNTING PLATE
|
BN
10 ga HRS 3.5 x 10.5
|
| 8. |
BN311601
|
[1] |
DASH PANEL
|
BN
RH, Chassis
|
| 9. |
86986653
|
[1] |
CONSOLE
|
BN
RH, Chassis
|
| 10. |
BN312833
|
[1] |
Gear Selector Panel Group., MD
|
|
| 11. |
BN2290807
|
[2] |
INDICATOR LIGHT
|
BN
Green
|
| 11A. |
BN2291235
|
[2] |
LAMP SOCKET
|
BN
Indicator Light
|
| 12. |
BN306846
|
[1] |
Parking Brake Valve Assem
|
|
| 13. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Air Seat Assembly
|
| 15. |
BN316082
|
[1] |
SHIELD
|
BN
Wiring Cab
|
| 15A. |
BN50053
|
[2] |
NUT
|
BN
Hex, 1/4"-20, G5 Superseded by part number: 280129
|
| 15B. |
BN2303140
|
[2] |
PLATE
|
BN
Washer, Flat 1/4 Superseded by part number: 80701
|
