凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (01-004) - STEERING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
608 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN2396330
|
[1] |
STEERING COLUMN
|
BN
Assembly
|
| . . |
BN2396330-001
|
[1] |
REPAIR KIT
|
BN
Turn Signal Repair Kit
|
| 2. |
BN2298398
|
[1] |
STEERING WHEEL
|
BN
|
| 3. |
BN2292560
|
[1] |
YOKE
|
BN
Assembly 902-01-49-694
|
| 4. |
BN315825
|
[4] |
LOCK NUT
|
BN
3/8-16, NLN, G8 Superseded by part number: 86625064
|
| 5. |
BN312561
|
[1] |
CAP
|
BN
Steering Wheel, Black
|
| 8. |
BN7142247
|
[1] |
MOUNTING PLATE
|
BN
Weldment, String Valve
|
| 10. |
BN315819
|
[1] |
PUMP
|
BN
Weldment, Steering Pump Mount
|
| 11. |
BN50254
|
[8] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 12. |
BN305108
|
[4] |
FLANGE BOLT,3/8" - 16, SST
|
BN
3/8-16, FLN, SS
|
| 13. |
9670285
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 8, Full Thd
|
GI
|
| 14. |
BN305106
|
[4] |
SCREW,3/8" - 24 x 3/4", Gr 8
|
BN
3/8-24 X .75, HH, G8 Superseded by part number: 86514065
|
| 15. |
BN300175
|
[6] |
WASHER
|
BN
3/8", G8
|
| 16. |
BN50146
|
[8] |
WASHER,3/8", Stainless
|
BN
|
| 19. |
BN2395066
|
[2] |
SEAL
|
BN
Trimseal, SD-161
|
| 20. |
BN305102
|
[4] |
SCREW,5/16", Gr 8
|
BN
5/16, LW, G8
|
| 21. |
BN305103
|
[4] |
SCREW,5/16" - 18 x 3/4", Gr 8
|
BN
5/16-18 X .75, HH, G8
|
| 23. |
BN305109
|
[2] |
FLANGE BOLT,7/16" - 20, Gr 8
|
BN
7/16-20, FLN, G8
|
| 24. |
BN50816
|
[2] |
7/16-20 X 1.5, HH, G8
|
|
