凯斯零件查询(FLX3300B) - FLOATER - 2002 (9/02-10/03) (01-013) - A\C HOSE KIT INSTALL GROUP {BN320811} Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
591 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN1470808
|
[2] |
NUT
|
BN
#10-32 Machine Zinc Superseded by part number: 225-14210
|
| 2. |
BN1914070
|
[2] |
SCREW,#10 - 32 x 3/4"
|
BN
#10-32 X 3/4 Machine
|
| 3. |
BN2294855
|
[3] |
O-RING
|
BN
#10 Neoprene (A/C)
|
| 4. |
BN2399320
|
[2] |
CLAMP
|
BN
Loom, Del City #2032
|
| 5. |
BN2294852
|
[5] |
O-RING
|
BN
#6 Neoprene (A/C)
|
| 6. |
BN2294854
|
[2] |
O-RING
|
BN
#8 Neoprene (A/C)
|
