Pos.	Part No	Qty	Parts name	Comments
1.	21FT-91020	[1]	HARNESS-ENGINE	110D-7E
1.	21FT-91021	[1]	HARNESS-ENGINE	110D-7E
1.	21FT-91023	[1]	HARNESS-ENGINE	110D-7E
1.	21FT-91020	[1]	HARNESS-ENGINE	130D-7E
1.	21FT-91021	[1]	HARNESS-ENGINE	130D-7E
1.	21FT-91023	[1]	HARNESS-ENGINE	130D-7E
1.	21FT-91030	[1]	HARNESS-ENGINE	140D-7E
1.	21FT-91031	[1]	HARNESS-ENGINE	140D-7E
1.	21FT-91033	[1]	HARNESS-ENGINE	140D-7E
1.	21FT-91030	[1]	HARNESS-ENGINE	160D-7E
1.	21FT-91031	[1]	HARNESS-ENGINE	160D-7E
1.	21FT-91033	[1]	HARNESS-ENGINE	160D-7E
1.	21FT-91033	[1]	HARNESS-ENGINE	160D-7E
1-1.	21N4-01310	[1]	LINK-FUSIBLE(30A)	RED
1-2.	21N4-01320	[1]	LINK-FUSIBLE(60A)	BLACK
1-1.	21N4-01310	[1]	LINK-FUSIBLE(30A)	RED
1-2.	21N4-01320	[1]	LINK-FUSIBLE(60A)	BLACK
1-3.	21EA-50550	[2]	DIODE-IN5406
1-3.	21EA-50550	[2]	DIODE-IN5406
2.	21FT-15053	[1]	HARNESS-FRAME	110D-7E
2.	21FT-15054	[1]	HARNESS-FRAME	110D-7E
2.	21FT-15053	[1]	HARNESS-FRAME	130D-7E
2.	21FT-15054	[1]	HARNESS-FRAME	130D-7E
2.	21FT-15053	[1]	HARNESS-FRAME	140D-7E
2.	21FT-15054	[1]	HARNESS-FRAME	140D-7E
2.	21FT-15053	[1]	HARNESS-FRAME	160D-7E
2.	21FT-15054	[1]	HARNESS-FRAME	160D-7E
