现代零件查询110/130/140/160D-7E OVERHEAD GUARD ELECTRICEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
539 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
21E6-10460
|
[3] |
COVER
|
|
| 2. |
21E6-30560
|
[1] |
SWITCH-INCHING
|
|
| 2-1. |
21E6-10440
|
[1] |
SWITCH-LOCKING TYPE
|
|
| 2-2. |
21E6-10620
|
[1] |
INSERT (CLUTCH CUT-OFF)
|
|
| 3. |
21E6-30570
|
[1] |
SWITCH-HAZARD
|
|
| 3-1. |
21E6-10600
|
[1] |
INSERT (HARZARD)
|
|
| 3-2. |
511107
|
[1] |
SWITCH
|
|
| 4. |
21FQ-10220
|
[1] |
SWITCH-AUTO
|
|
| 4-1. |
21L7-03010
|
[1] |
SWITCH-OFF-1-2
|
|
| 4-2. |
24L1-02010
|
[1] |
INSERT-FULL AUTOMATIC
|
|
| 5. |
21FT-10470
|
[2] |
PLATE
|
|
| 6. |
21FT-15100
|
[1] |
SWITCH-CRUISE
|
|
| 6-1. |
21E6-10440
|
[1] |
SWITCH-LOCKING TYPE
|
|
| 6-2. |
21FT-15110
|
[1] |
INSERT CRUISE CONTROL
|
|
| 7. |
21FT-15120
|
[1] |
SWITCH-CRUISE SET
|
|
| 7-1. |
21FT-15140
|
[1] |
INSERT CRUISE SET-RESUME
|
|
| 7-2. |
21FT-15130
|
[1] |
SWITCH
|
|
| 8. |
21FT-15161
|
[2] |
PLATE
|
|
| 9. |
21FT-15312
|
[1] |
CLUSTER
|
|
| 10. |
21FT-15320
|
[1] |
SWITCH-ALT TORQUE
|
|
| 10-1. |
21E6-10440
|
[1] |
SWITCH-LOCKING TYPE
|
|
| 11. |
21FT-15371
|
[1] |
ACCELERATOR PEDAL
|
|
| 12. |
21FT-15380
|
[1] |
BEACON LAMP
|
|
| 12-1. |
21HA-21140
|
[1] |
XENON LAMP
|
|
| 12-2. |
21HA-21110
|
[1] |
LENS-BEACON, AMBER
|
|
| 13. |
21FT-15390
|
[1] |
BEACON LAMP
|
|
| 13-1. |
21HA-21120
|
[1] |
LENS-BEACON, RED
|
|
| 13-2. |
21HA-21140
|
[1] |
XENON LAMP
|
|
| 14. |
21FT-15400
|
[1] |
BEACON LAMP
|
|
| 14-1. |
21HA-21130
|
[1] |
LENS-BEACON, BLUE
|
|
| 14-2. |
21HA-21140
|
[1] |
XENON LAMP
|
|
| 15. |
21FT-15440
|
[1] |
BRACKET
|
|
| 16. |
21FT-15461
|
[1] |
START KEY SW
|
|
| N16-2. |
21Q4-00080
|
[8] |
ROTTO
|
|
| N16-3. |
21Q4-10500
|
[1] |
KEY-START
|
|
| 17. |
21FT-15471
|
[1] |
SWITCH ASSY-INCL KEY
|
|
| 17-2. |
21FT-15480
|
[8] |
ROTTO
|
|
| 17-3. |
21Q4-10400
|
[1] |
KEY-START
|
|
| 18. |
21FT-15590
|
[1] |
SWITCH-PARKING W/ LOCK
|
|
| 18-1. |
21E6-10610
|
[1] |
INSERT,PARKING
|
|
| 18-2. |
21L7-03030
|
[1] |
SWITCH-SWF
|
|
| 19. |
21FT-15780
|
[1] |
SWITCH-FUEL HEATER
|
|
| 19-1. |
21E6-10440
|
[1] |
SWITCH-LOCKING TYPE
|
|
| 19-2. |
21FT-15790
|
[1] |
INSERT-FUEL HEATER
|
|
| 20. |
21FT-15900
|
[1] |
FDCU
|
|
| 21. |
21FT-91010
|
[1] |
HARNESS-MAIN
|
|
| 21. |
21FT-91011
|
[1] |
HARNESS-MAIN
|
|
| 21. |
21FT-91010
|
[1] |
HARNESS-MAIN
|
|
| 21. |
21FT-91011
|
[1] |
HARNESS-MAIN
|
|
| 21. |
21FT-91010
|
[1] |
HARNESS-MAIN
|
|
| 21. |
21FT-91011
|
[1] |
HARNESS-MAIN
|
|
| 21. |
21FT-91010
|
[1] |
HARNESS-MAIN
|
|
| 21. |
21FT-91011
|
[1] |
HARNESS-MAIN
|
|
| 22. |
21FT-90040
|
[1] |
HARNESS HEAD GUARD
|
|
| 23. |
21FU-10614
|
[1] |
OPSS UNIT
|
|
| 24. |
21L6-06240
|
[1] |
SWITCH-IN/DECREMENT
|
|
| 25. |
21L6-20140
|
[1] |
SWITCH-WORK LAMP
|
|
| 25-1. |
21L7-03010
|
[1] |
SWITCH-OFF-1-2
|
|
| 26. |
21L7-03090
|
[1] |
SWITCH-MAIN LIGHT
|
|
| 26-1. |
21L7-03010
|
[1] |
SWITCH-OFF-1-2
|
|
| 26-2. |
21L7-02170
|
[1] |
INSERT-MAIN LIGHT
|
|
| 27. |
21N4-01130
|
[2] |
PLATE-CLIP
|
|
| 28. |
21N6-20211
|
[2] |
WORK LAMP ASSY
|
|
| 29. |
24L3-00340
|
[1] |
SWITCH-MULTIFUNCTION
|
|
| 30. |
25D1-10640
|
[1] |
CLIP ASSY
|
|
| 31. |
25D1-10640
|
[1] |
CLIP ASSY
|
|
| 32. |
25D1-10650
|
[1] |
CLIP ASSY
|
|
| 33. |
25FQ-10290
|
[1] |
ALARM
|
|
| 40. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 41. |
S035-061526
|
[8] |
BOLT-W/WASHER
|
|
| 42. |
S035-081526
|
[19] |
BOLT-W/WASHER
|
|
| 43. |
S035-082026
|
[2] |
BOLT-W/WASHER
|
|
| 44. |
S035-082026
|
[6] |
BOLT-W/WASHER
|
|
| 45. |
S131-053046
|
[4] |
SCREW-W/WASHER
|
|
| 46. |
S542-200002
|
[2] |
CLAMP-TUBE
|
|
| 47. |
S543-100002
|
[2] |
CLAMP-TUBE
|
|
| 48. |
S543-140002
|
[2] |
CLAMP-TUBE
|
|
| 49. |
S543-200002
|
[3] |
CLAMP-TUBE
|
|
| 50. |
S543-240002
|
[1] |
CLAMP-TUBE
|
|
| 51. |
S543-300002
|
[1] |
CLAMP-TUBE
|
|
| 52. |
S661-260300
|
[1] |
CAP-RUBBER
|
|
| 53. |
S791-020010
|
[1] |
GROMMET-PLATE
|
|
| 54. |
S880-125030
|
[1] |
GROMMET
|
|
| 55. |
S880-125030
|
[2] |
GROMMET
|
|
