神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (08-002[02]) - CONTROL VALVE ASSY P/N LB30V00004F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
989 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LB30V00004F1 | [1] | CONTROL VALVE | KOBAssembly, Independent Travel |
| 101. | LB30V00004S101 | [1] | BODY | KOBBODY |
| 301. | LB30V00004S301 | [2] | SPOOL | KOBSPOOL |
| 321. | LB30V00004S321 | [2] | SPRING | KOBSPRING |
| 322. | LB30V00004S322 | [2] | SPRING | KOBSPRING |
| 331. | LB30V00004S331 | [2] | STOP | KOBSTOPPER |
| 351. | 2436U1444S351 | [2] | PLUG | KOBPLUG |
| 352. | LB30V00004S352 | [2] | PLUG | KOBPLUG |
| 361. | ZD12G02500 | [2] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 362. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 977. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 978. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
