| . . | LC30V00004F1 | [1] | PILOT VALVE | KOBASSY, (PROPELLING) |
| . . | LC30V00004F2 | [1] | PILOT VALVE | KOBASSY, (PROPELLING) |
| 1. | 2436U1142S13 | [1] | SHIM | KOBSHIM (0.1), QTY-F1: 2, QTY-F2: 2 |
| 2. | 2436U1487S7 | [1] | SHIM | KOBSHIM (0.2), QTY-F1: 2, QTY-F2: 2 |
| 3. | 2436U2755S4 | [1] | SEAT | KOBSHEET, QTY-F1: 1, QTY-F2: 1 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL, QTY-F1: 2, QTY-F2: 2 |
| 5. | 2436U1354S5 | [1] | SLEEVE | KOBSLEEVE, QTY-F1: 2, QTY-F2: 2 |
| 6. | 2436U1354S6 | [1] | COVER | KOBCOVER, QTY-F1: 1, QTY-F2: 1 |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONROD, PUSH, QTY-F1: 2, QTY-F2: 2 |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONBODY, QTY-F1: 1, QTY-F2: - |
| 9. | YR30V00004S012 | [1] | SPRING | KOBSPRING, QTY-F1: 2, QTY-F2: 2 |
| 10. | YR30V00013S009 | [1] | SPRING | KOBSPRING, QTY-F1: 2, QTY-F2: 2 |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE, QTY-F1: 1, QTY-F2: 1 |
| 12. | 2436U1354S25 | [1] | SHIM | KOBSHIM (0.2), QTY-F1: 2, QTY-F2: 2 |
| 13. | YR30V00013S012 | [1] | SHIM | KOBSHIM (0.1), QTY-F1: 2, QTY-F2: 2 |
| 14. | YN30V00022S015 | [1] | CAM | KOBCAM, QTY-F1: 1, QTY-F2: 1 |
| 15. | YN30V00022S016 | [1] | BOOT | KOBBOOT, QTY-F1: 1, QTY-F2: 1 |
| 16. | YN30V00022S017 | [1] | PIN | KOBPIN, QTY-F1: 1, QTY-F2: 1 |
| 18. | 2436U2412S26 | [1] | PLUG | KOB1/4"PF, QTY-F1: 1, QTY-F2: 1 |
| 19. | ZS23C12020 | [1] | CAPSCREW,Hex Socket Head, M12 x 20mm | KOBSCREW M12x1.75x20mm, QTY-F1: 1, QTY-F2: 1 |
| 20. | 2436U1354S15 | [1] | BOLT | KOBCAPSCREW, QTY-F1: 2, QTY-F2: 2 |
| 21. | ZS83C08008 | [1] | SCREW | KOBSet -- M08x1.25x08mm, QTY-F1: 2, QTY-F2: 2 |
| 22. | 2436U1354S16 | [1] | WASHER | KOBWASHER, QTY-F1: 2, QTY-F2: 2 |
| 23. | 2436U1487S35 | [1] | RIVET | KOBSCREW, QTY-F1: 2, QTY-F2: 2 |
| 24. | 2436U1354S19 | [1] | PIN | KOBPIN, SPRING, QTY-F1: 2, QTY-F2: 2 |
| 25. | NSS | [1] | NOT SOLD SEPARAT | CONBALL, QTY-F1: 1, QTY-F2: 1 |
| 26. | NSS | [1] | NOT SOLD SEPARAT | CONBALL, QTY-F1: 3, QTY-F2: 3 |
| 27. | ZD11P01000 | [1] | O-RING | KOBID 9.8 ± 0.17 x OD 13.6mm, QTY-F1: 2, QTY-F2: 2 |
| 28. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm, QTY-F1: 1, QTY-F2: 1 |
| 29. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm, QTY-F1: 2, QTY-F2: 2 |
| 30. | NSS | [1] | NOT SOLD SEPARAT | CONBODY, QTY-F1: -, QTY-F2: 1 |
| . . | 2436U1354S26 | [1] | PISTON | KOBREPAIR KIT CONSISTS OF ITEM 7X1,26X1, QTY-F1: 2, QTY-F2: 2 |
