神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (08-007) - BUCKET CYLINDER ASSEMBLY, P/N YM01V00009F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
821 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YM01V00009F1 | [1] | CYLINDER | KOBBucket Cylinder Assembly Superseded by part number: YM01V00009F4 |
| .. | YM01V00009F2 | [1] | CYLINDER | KOBBucket Cylinder Assembly Superseded by part number: YM01V00009F4 |
| .. | YM01V00009F3 | [1] | CYLINDER | KOBBucket Cylinder Assembly Superseded by part number: YM01V00009F4 |
| .. | YM01V00009F4 | [1] | HYDRAULIC CYLINDER | KOBBucket Cylinder Assembly |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCYLINDER HEAD |
| 4. | 2438U1949S4 | [1] | BUSHING | KOB |
| 5. | 2438U1949S5 | [1] | RING | KOB |
| 7. | 2438U814S31 | [1] | RING | KOBU |
| 8. | 2438U814S32 | [1] | RING | KOBBack-Up |
| 9. | LP01V00007S009 | [1] | RING | KOBWiper |
| 10. | ZD12G10000 | [1] | O-RING,99.40mm ID x 105.60mm OD x 3.10mm | KOBID 99.40 � 0.85 x OD 105mm |
| 11. | PZ01V00003S008 | [1] | RING | KOBBack-Up |
| 12. | ZS23C14065 | [12] | BOLT,Hex Socket Head, M14 x 65mm | KOBM14x2.0x65mm |
| 13. | YM01V00009S013 | [1] | BEARING | KOB |
| 14. | YM01V00009S014 | [1] | SEAL | KOB |
| 15. | YM01V00009S015 | [1] | PISTON | KOB |
| 16. | 2438U676S21 | [1] | RING | KOBSeal |
| 17. | YM01V00009S017 | [2] | RING | KOBBack-Up |
| 18. | YM01V00009S018 | [2] | RING | KOB |
| 19. | 2438U814S23 | [2] | RING | KOB |
| 20. | 2438U1094S21 | [1] | SHIM | KOB |
| 21. | YM01V00009S020 | [1] | NUT | KOB |
| 22. | 2438U999S21 | [1] | SET SCREW | KOBSet -- M12x1.75mm |
| 23. | 2436U330S16 | [1] | BALL | KOB |
| 25. | 2438U1949S23 | [4] | RING | KOB |
| 26. | YM01V00009S026 | [1] | STRAP | KOB |
| 27. | LE01V00009S028 | [1] | BAND | KOBAssembly |
| 28. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 29. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 30. | 2438U1949S22 | [2] | BUSHING,70mm ID x 80mm OD x 90mm W | KOB~F1 (2 ea) Superseded by part number: YM01V01010P1 |
| 30. | YM01V01004P1 | [1] | BUSHING,70mm ID x 80mm OD x 90mm W | KOB~F2 (2 ea), ~F3 (2 ea), ~F4 (1 ea) |
| 31. | YM01V00009S031 | [1] | RING | KOBBuffer |
| 32. | NSS | [1] | NOT SOLD SEPARAT | CONTube Cylinder |
| 33. | NSS | [1] | NOT SOLD SEPARAT | CONRod and Piston Assembly |
| 34. | YM01V01010P1 | [1] | BUSHING,70.28mm ID x 80mm OD x 90mm L | KOB~F4 (1 ea - Rod End) |
| . . | YM01V00009R100 | [1] | REPAIR KIT | KOBContains Items 7-11 & 31 Superseded by part number: YB01V00011R100 |
| . . | YM01V00009R200 | [1] | REPAIR KIT | KOBContains Items 16-19 |
| . . | YM01V00009R300 | [1] | REPAIR KIT | KOBContains Items 7-11, 16-19 & 31 Superseded by part number: YB01V00011R300 |
| . . | YM01V00009R400 | [1] | REPAIR KIT | KOBContains Items 30 & 32 (~F1 only) Superseded by part number: YM01V00009R700 |
| . . | YM01V00009R600 | [1] | REPAIR KIT | KOBContains Items 3 & 4 |
| . . | YM01V00009R700 | [1] | CYLINDER | KOBContains Items 30 & 32 (~F2 thru ~F4 only) |
| . . | YM01V00009R900 | [1] | CYLINDER | KOBContains Items 33 & 34 |
