| . . | YM30V00003F1 | [1] | VALVE ASSY,CONTROL | |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASE |
| 102. | NSS | [1] | NOT SOLD SEPARAT | CONCASE |
| 155. | YW30V00001S155 | [2] | PLUG | KOB1/2" |
| 156. | YN30V00001S156 | [3] | PLUG | KOB(ROH-3/8) Superseded by part number: YW30V00001S156 |
| 158. | YN30V00001S158 | [1] | PLUG | KOB(ROH-1/8) |
| 162. | ZD12G03000 | [17] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 163. | ZD12P01500 | [3] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 164. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 166. | ZD12P01400 | [3] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 168. | ZD12P00800 | [1] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 201. | 2436U1265S201 | [8] | COVER | KOBSPRING Superseded by part number: 2436U2631S201 |
| 204. | YN30V00021S207 | [4] | COVER | KOBSPRING |
| 206. | 2436U1265S203 | [8] | COVER | KOBSPOOL |
| 211. | YX30V00009F1 | [2] | LOCK VALVE | KOBASSY |
| 214. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 215. | NSS | [1] | NOT SOLD SEPARAT | CONVALVE ASSY |
| 262. | 2436U1457S162 | [12] | O-RING,2mm Thk x 39.5mm ID, 90 Duro | KOB |
| 265. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 271. | NSS | [4] | NOT SOLD SEPARAT | CONSCREW |
| 272. | NSS | [4] | NOT SOLD SEPARAT | CONSCREW |
| 273. | ZS23C08025 | [40] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 301. | YB30V00003S301 | [1] | REPAIR KIT | KOBASSY, BOOM Superseded by part number: YB30V00003R100 |
| 302. | YM30V00003S302 | [1] | SPOOL | KOBARM Superseded by part number: YM30V00003R140 |
| 303. | YM30V00003S303 | [1] | SPOOL ASSY, SWING | |
| 304. | YM30V00003S304 | [1] | SPOOL | KOBBUCKET Superseded by part number: YM30V00003R110 |
| 305. | YW30V00006S305 | [1] | SPOOL | KOBBOOM CONFLUENCE Superseded by part number: YW30V00006R150 |
| 306. | YW30V00006S306 | [2] | SPOOL, TRAVEL | |
| 307. | YM30V00003S307 | [1] | SPOOL,STRAIGHT TRAVEL | |
| 308. | YW30V00001S308 | [1] | SPOOL | KOBARM CONFLUENCE Superseded by part number: YW30V00001R160 |
| 309. | LP30V00004S312 | [2] | REPAIR KIT | KOBSPOOL, BYPASS CUT Superseded by part number: LP30V00004R120 |
| 310. | YB30V00003S310 | [1] | SPOOL | KOBARM REGENERATION Superseded by part number: YB30V00003R140 |
| 324. | YX30V00011S324 | [3] | SPRING | KOB |
| 325. | YN30V00001S325 | [8] | SPRING | KOB |
| 326. | YN30V00001S326 | [6] | SPRING | KOB |
| 327. | YN30V00001S327 | [2] | SPRING | KOB |
| 328. | YX30V00011S328 | [1] | SPRING | KOB |
| 329. | 2436U1265S322 | [4] | SPRING | KOB |
| 332. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 333. | 2436U1265S336 | [12] | BOLT | KOBSPACER |
| 337. | 2436U1265S335 | [10] | STOP | KOB |
| 338. | YN30V00001S338 | [2] | STOP | KOB |
| 512. | 2436U1265S511 | [9] | POPPET | KOB |
| 513. | YW30V00001S513 | [2] | POPPET | KOB |
| 514. | YW30V00001S514 | [2] | POPPET | KOB |
| 515. | YN30V00001S515 | [1] | POPPET | KOBPOPPET |
| 517. | YY30V00015S517 | [1] | POPPET | |
| 522. | 2436U1265S521 | [12] | SPRING | KOB |
| 524. | YW30V00001S524 | [2] | SPRING | KOB |
| 527. | YY30V00015S527 | [1] | SPRING | |
| 552. | YN30V00001S552 | [13] | PLUG | KOB(ROMH-22) Superseded by part number: YN30V00021S552 |
| 556. | YW30V00001S556 | [2] | PLUG | KOB |
| 557. | YY30V00015S557 | [1] | PLUG (M22, tp 1.5) | |
| 562. | ZD12P02000 | [16] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 601. | YN22V00001F3 | [1] | VALVE | KOBRELIEF, MAIN (SEE P. YN22V00001-1) |
| 602. | YN22V00002F1 | [3] | VALVE | KOBRELIEF, PORT (SEE P. YN22V00002-1) |
| 603. | YN22V00002F9 | [3] | VALVE | KOBRELIEF, PORT (SEE P. YN22V00002-1) |
| 973. | ZS23C14110 | [7] | SET SCREW,Hex Socket Head, M14 x 110mm | KOBM14x2.0x110mm |
| 974. | ZS23C14075 | [1] | CAPSCREW,Hex Socket Head, M14 x 75mm | KOBSCREW M14x2.0x75mm |
| 977. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 987. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
| . . | YB30V00003R100 | [1] | REPAIR KIT | KOB |
| . . | YM30V00003R100 | [1] | CONTROL VALVE | KOBREPAIR KIT Superseded by part number: YM30V00003R140 |
| . . | YM30V00003R110 | [1] | REPAIR KIT | KOB |
| . . | YM30V00003R120 | [1] | CONTROL VALVE | KOBREPAIR KIT |
| . . | YW30V00006R130 | [1] | SPOOL | KOBSPOOL |
| . . | YM30V00003R130 | [1] | REPAIR KIT | |
| . . | YW30V00006R150 | [1] | SPOOL | KOBKIT |
| . . | YW30V00001R160 | [1] | SPOOL | KOBASSY |
| . . | LP30V00004R120 | [1] | REPAIR KIT | KOB |
| . . | YB30V00003R140 | [1] | REPAIR KIT | KOBREPAIR KIT |
