| . . | YM64H00006F1 | [1] | CONTROL UNIT | KOBCONTORL LINES, REMOTE(MULTl) Superseded by part number: YT42H01128P1, ZS18C08020, ZW16X08000, YN64H01078DA, ZH42X06000, ZH32X06000, YN20T01475P1, KSP9000-0032, YN64H01018P1, ZH22F06000, YN64H01078D8, YN20T01476P1, PY01P01043D8, ZE72X06000, YY30V00019F1 |
| 1. | YY30V00019F1 | [1] | VALVE | KOBVALVE, CONTROL,See C.P.M |
| 2. | YN64H01078D8 | [5] | HOSE | KOBPF3/8, 600mm Long (23-5/8 in) |
| 3. | YN64H01078DA | [3] | HOSE | KOBPF 3/8, 780mm Long (30-45/64 in) |
| 4. | YN64H01018P1 | [1] | GROMMET | KOBGROMMET |
| 5. | PY01P01043D6 | [6] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 6. | ZH22F06000 | [4] | CONNECTION | KOBCONNECTOR,(PF 3/8) |
| 7. | ZH42X06000 | [4] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006), (PF 3/8) |
| 3. | ZH32X06000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 9. | 2444Z3155 | [4] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (PF 3/8) (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1 |
| 10. | ZE72X06000 | [8] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 11. | ZS18C08020 | [4] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 12. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 13. | PW02B01209P1 | [1] | GROMMET | KOBReplaces PH02B01058P1 Date 09/15/2000 - 02/02/2001 |
