神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (04-002) - ELEMENT KIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
314 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30T00001F1 | [1] | ELEMENT KIT | |
| 1. | 2446R332D5 | [1] | ELEMENT | KOBFUEL Superseded by part number: 2451R124-2A |
| . . | VAME016823 | [1] | ELEMENT | KOB Superseded by part number: 2451R124-2A |
| 2. | 2446R332D12 | [1] | FILLER | KOBOIL,(ME215002) Superseded by part number: 84218257 |
| 3. | YM91Z00001D1 | [1] | OPERATOR MANUAL | KOB |
| 4. | YM91Z00002D1 | [1] | MANUAL, PARTS | |
| 5. | 2445Z1570 | [4] | O-RING,9mm Thk x 125mm ID, Cl 5, 75 Duro | KOBID 125 ± 0.40 x OD 143mm |
