| . . | YM60D00001F1 | [1] | SHOE | KOBASSY (600mm), QTY-F1: F1, QTY-F2: -, QTY-F3: -, QTY-F4: -, QTY-F5: - |
| . . | YM60D00001F2 | [1] | SHOE | KOBASSY (500mm), QTY-F1: -, QTY-F2: F2, QTY-F3: -, QTY-F4: -, QTY-F5: - |
| . . | YM60D00001F3 | [1] | SHOE ASSY (700mm), QTY-F1: -, QTY-F2: -, QTY-F3: F3, QTY-F4: -, QTY-F5: - | SHOE ASSY (700mm), QTY-F1: -, QTY-F2: -, QTY-F3: F3, QTY-F4: -, QTY-F5: - |
| . . | YM60D00001F4 | [1] | SHOE | KOBASSY (800mm), QTY-F1: -, QTY-F2: -, QTY-F3: -, QTY-F4: F4, QTY-F5: - |
| . . | YM60D00001F5 | [1] | SHOE | KOBASSY (700mm) (Double Grouser), QTY-F1: -, QTY-F2: -, QTY-F3: -, QTY-F4: -, QTY-F5: F5 |
| 1. | YM62D00001F1 | [1] | TRACK LINK | KOBASSY, QTY-F1: 1, QTY-F2: 1, QTY-F3: 1, QTY-F4: 1, QTY-F5: 1 |
| 1-1. | 2424J376 | [1] | TRACK LINK | KOB(R), QTY-F1: 45, QTY-F2: 45, QTY-F3: 45, QTY-F4: 45, QTY-F5: 45 Superseded by part number: 2424J171D1 |
| 1-2. | 2424J377 | [1] | TRACK LINK | KOB(L), QTY-F1: 45, QTY-F2: 45, QTY-F3: 45, QTY-F4: 45, QTY-F5: 45 |
| 1-3. | 2405P416 | [44] | BUSHING,37.1mm ID x 58.73mm OD x 142.97mm L | KOBID 37.1 x OD 58.73 x 142.97mm Long, QTY-F1: 44, QTY-F2: 44, QTY-F3: 44, QTY-F4: 44, QTY-F5: 44 |
| 1-4. | 2419P4210 | [1] | PIN,36.66mm OD x 206.40mm L | KOBOD 36.6 x 206.4mm Long, QTY-F1: 44, QTY-F2: 44, QTY-F3: 44, QTY-F4: 44, QTY-F5: 44 Superseded by part number: 2419T6091 |
| 1-5. | 2405P415 | [1] | BUSHING | KOBID 37.1 x OD 58.73 x 128.71mm Long, QTY-F1: 1, QTY-F2: 1, QTY-F3: 1, QTY-F4: 1, QTY-F5: 1 Superseded by part number: 2405P392 |
| 1-6. | 2419P4211 | [1] | PIN,36.5mm OD x 206.4mm L | KOBOD 36.5 x 206.4mm Long, QTY-F1: 1, QTY-F2: 1, QTY-F3: 1, QTY-F4: 1, QTY-F5: 1 |
| 1-7. | 2418T21131 | [1] | COLLAR | KOBQTY-F1: 2, QTY-F2: 2, QTY-F3: 2, QTY-F4: 2, QTY-F5: 2 |
| 1-8. | 2445Z1449 | [1] | SEAL,40mm ID x 59.8mm OD x 5.7mm Thk | KOBQTY-F1: 88, QTY-F2: 88, QTY-F3: 88, QTY-F4: 88, QTY-F5: 88 |
| 2. | YM60D00002P1 | [1] | SHOE | KOB(600mm), QTY-F1: 45, QTY-F2: -, QTY-F3: -, QTY-F4: -, QTY-F5: - |
| 3. | 2420T6976 | [1] | BOLT,Spher Hex, M20 x 1.5 x 56.50mm, Cl 2 | KOBM20x1.50x56.5mm, QTY-F1: 1, QTY-F2: 180, QTY-F3: 180, QTY-F4: 180, QTY-F5: 180 Superseded by part number: 47796204 |
| 4. | 2420P1552 | [1] | NUT,M20, 1.5mm Pitch, HT | KOBM20x1.50mm, QTY-F1: 180, QTY-F2: 180, QTY-F3: 180, QTY-F4: 180, QTY-F5: 180, Remarks: (M20, tp 1.5) Superseded by part number: 2420P1584 |
| 5. | YM60D00004P1 | [1] | SHOE | KOB(500mm), QTY-F1: -, QTY-F2: 45, QTY-F3: -, QTY-F4: -, QTY-F5: - |
| 6. | YM60D00005P1 | [1] | SHOE | KOB(700mm), QTY-F1: -, QTY-F2: -, QTY-F3: 45, QTY-F4: -, QTY-F5: - |
| 7. | LQ60D00017P1 | [1] | SHOE | KOB(800mm), QTY-F1: -, QTY-F2: -, QTY-F3: -, QTY-F4: 45, QTY-F5: - |
| 8. | YN60DU0001P1 | [1] | SHOE | KOB(DBL GROUSER 700mm), QTY-F1: -, QTY-F2: -, QTY-F3: -, QTY-F4: -, QTY-F5: 45 |
