凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (02-009) - TURBOCHARGER ASSEMBLY (FLX3300B CASE ENGINE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
647 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
J800426
|
[1] |
SERVICE KIT
|
CAS
Turbocharger Superseded by part number: JR800426
|
| . . |
JR800426
|
[1] |
REMAN-TURBOCHARGER
|
CAS
FLX3300B
|
| . . |
JC590348
|
[1] |
CORE-TURBOCHARGER
|
CAS
Return Part Number
|
| 1. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Turbocharger
|
| 17. |
J759917
|
[6] |
SET SCREW
|
CAS
|
| 18. |
J537960
|
[1] |
GASKET,0.46mm Thk
|
CAS
Housing
|
| 19. |
J537979
|
[1] |
ADAPTER
|
CAS
|
| 20. |
120104
|
[5] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 21. |
J533163
|
[1] |
SNAP RING
|
CAS
|
| 22. |
J534309
|
[2] |
PLATE
|
CAS
Kit, Overhaul
|
| . . |
J575169
|
[1] |
REPAIR KIT
|
CAS
Overhaul
|
