凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (02-012) - OIL PUMP & OIL PAN (FLX3300B CASE ENGINE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
129 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
J942723
|
[1] |
PUMP, ENGINE OIL
|
CAS
Assembly, New Superseded by part number: J948072
|
| 1. |
JR942723
|
[1] |
REMAN-ENG OIL PUMP
|
CAS
REMAN-ENGINE OIL PUMP Assembly, Remanufactured Superseded by part number: JR948072
|
| 1. |
JC942723
|
[1] |
CORE-ENGINE OIL PUMP
|
CAS
CORE-ENGINE OIL PUMP Return Number
|
| 2. |
J900677
|
[4] |
BOLT,Hex
|
CAS
M8 X 30 Superseded by part number: J900677AM
|
| 3. |
J910787
|
[1] |
TUBE
|
CAS
|
| 4. |
J926865
|
[2] |
SPACER,6.9mm ID x 12.7mm OD x 14mm L
|
CAS
|
| 5. |
845-6030
|
[2] |
BOLT,Hvy Hex, M6 x 30mm, Cl 8.8
|
CAS
|
| 6. |
J914302
|
[1] |
GASKET
|
CAS
Mounting Superseded by part number: 87447959
|
| 7. |
J927611
|
[1] |
BRACKET
|
CAS
Brace Superseded by part number: J927611AM
|
| 8. |
87015915
|
[2] |
BOLT,Hvy Hex, M6 x 15mm, Cl 8.8, Full Thd
|
RAC
|
| 9. |
87015862
|
[1] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8, Full Thd
|
WIC
|
| 10. |
J910960
|
[1] |
WASHER
|
IH
Superseded by part number: J910960AM
|
| 11. |
J906216
|
[1] |
FLANGE NUT
|
IH
Flange, M6 Superseded by part number: 9804276
|
| 12. |
J933347
|
[1] |
ENGINE OIL PAN
|
CAS
Superseded by part number: 87362733
|
| 13. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Seal, Order : A77679
|
| 14. |
J920400
|
[32] |
FLANGE BOLT,Hex, M8 x 1.25 x 21mm, Gr 8.8
|
CAS
|
| 15. |
J910266
|
[32] |
LOCK WASHER
|
IH
Spring Superseded by part number: 11197879
|
| 16. |
J908316
|
[32] |
WASHER
|
IH
M9 X 16 X 1
|
| 17. |
J924147
|
[1] |
PLUG,M18 x 1.5
|
CAS
Hex, M18
|
| 18. |
J920773
|
[1] |
SEALING WASHER
|
CAS
Superseded by part number: 16508360
|
| . . |
A77679
|
[1] |
GASKET KIT
|
CAS
Oil Pan Superseded by part number: 16508360, J902425, 87447959, 87308050
|
