神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-013) - ENGINE CONTROL ASSEMBLY (YM11M00001F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
719 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YM11M01018P2 | [1] | Bracket | |
| 2. | YM11M01025P1 | [1] | LEVER | KOB |
| 3. | YN11M01091P1 | [1] | LEVER | KOB |
| 4. | YT20S00002F3 | [1] | GOVERNOR | KOBMotor -- No Service Parts |
| 5. | YN11M01006P1 | [1] | ROD | KOB |
| 6. | HR37C08000G1 | [1] | BALL JOINT | KOBReplaces 2425R227D2, M08x1.25x45.5mm Long |
| 7. | ZN18C08007 | [3] | NUT | KOBM08x1.25mm |
| 8. | ZM22C10030 | [2] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| 9. | ZW26X10000 | [3] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 10. | YM11M01026P1 | [1] | Bracket | |
| 11. | 2420R766D3 | [1] | GROMMET | KOB |
| 12. | ZS28C06025 | [1] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 13. | ZW26X06000 | [3] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 14. | ZS18C06060 | [2] | SCREW,Hex, M6 x 60mm | KOBM06x1.0x60mm |
| 15. | YN11M01013D1 | [1] | BALL JOINT | KOBM08x1.25x36mm Long (Left hand thread) Superseded by part number: HR37D08000G1 |
| 16. | 2419R9D1 | [2] | COTTER PIN | KOBOD 06mm x 21.2mm Long |
| 17. | 2420T7359 | [1] | NUT | KOBM08x1.25mm -- Left Hand Threads |
| 18. | YN11M01114P2 | [2] | PIN | KOB Superseded by part number: ZP45X06018 |
| 19. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 20. | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 21. | YN11M01079P1 | [2] | BOSS | KOB |
| 22. | ZS28C10035 | [3] | SCREW,Hex Socket Head, M10 x 35mm | KOBScrew -- M10x1.50x35mm |
| 23. | YM11M01014P1 | [1] | CABLE | KOB4254mm Long (167-1/2 in) |
| 24. | YM11M01017P1 | [1] | BRACKET | KOB |
| 25. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 26. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 27. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 28. | 2420Z1320D1 | [1] | END | KOBRod -- Used from date 03/10/2000 - 03/30/2001 Superseded by part number: PM03M01715F1 |
| . . | LC11M01034P1 | [1] | ROD | KOBEnd -- Used after date 03/30/2001 - Up |
| 29. | ZN18C06005 | [1] | NUT | KOBM06x1.0mm |
| 30. | 2420Z1330 | [1] | GROMMET | KOB |
| 31. | 2432T4615 | [1] | LABEL | KOBDecal -- 45x45mm Red triangle |
| 32. | LQ11M01055P1 | [1] | U-BRACKET | KOB |
| 33. | ZM61C06016 | [2] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 34. | YM11M01016P1 | [1] | CABLE | KOB4226mm Long (166-3/8 in) -- Used from date 03/10/2000 - 04/21/2001 Superseded by part number: YM11M01016P2 |
| . . | YM11M01016P2 | [1] | CABLE | KOB4180mm Long (164-1/2 in) -- Cable, Control -- Used after date 04/21/2001 - Up |
| 35. | 2420T4505 | [2] | WASHER,7mm ID x 16mm OD x 1mm Thk | KOBID 07 x OD 16 x Th 1.0mm |
