神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-018[01]) - UPPER HYDRAULIC LINES (SUCTION DELIVERY), P/N YM30H00001F1, PAGE 1 OF 2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
369 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30H00001F1 | [1] | HYD LINES, PUMP (SUCTION, DELIVERY), Page 1 of 2 | |
| 1. | ZX30U12086 | [1] | FLEXIBLE HOSE | KOB(P1 DELIVERY), 860mm Long (33-49/64 in) |
| 2. | ZX30U12094 | [1] | HOSE | KOB(R2 DELIVERY), 940mm Long (37 in) |
| 3. | YM30H01003P1 | [1] | HOSE | KOB(SUCTION) |
| 7. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 13. | ZC16X09100 | [4] | CLIP | KOBClamp, Hose -- Min 80 x Max 101mm |
| 18. | ZW16H10000 | [5] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 19. | ZW16H12000 | [4] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 23. | ZX40H10074 | [2] | HOSE,740.00 mm, SAE 100R13 | KOB1-14UNS |
| 25. | ZA23F15008 | [1] | HYD CONNECTOR | KOB(PF 1/2) |
| 26. | ZG23F10008 | [2] | HYD CONNECTOR | KOB1-14UNS x 1/2" PF x 43.5mm (5/8x1/2) (Incls. O-Ring 237-6008) |
| . . | ZD12P02400 | [1] | O-RING | KOB(Part of ZG33F10008), ID 23.70 ± 0.24 x OD 30mm, Not Shown |
| 27. | ZG33F10008 | [2] | 90 ELBOW,1"-14 UNS x PF 1/2" | KOB90° -- 1" -14UNS x 1/2" PF (Incls. O-Ring ZD12P01800) |
| . . | ZD12P01800 | [1] | O-RING | KOB(Part of ZG33F10008), ID 17.8mm x OD 20.2mm, Not Shown |
| 28. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 29. | ZD12A01600 | [4] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 31. | LB30V00004F1 | [1] | CONTROL VALVE | KOBIndependent Travel |
| 33. | YM30H01001P1 | [1] | BRACKET | |
| 34. | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 39. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 41. | 2444Z3715 | [1] | 90 ELBOW | KOB90° -- 1/2" PF x 56mm Long (Incls. O-Ring ZD12P01800) |
| 43. | 2420T4361 | [1] | PLUG | KOB1-1/4" PF x 40mm Long, (Incls. O-Ring ZD12P03800) |
| 44. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
