神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-017) - VALVE INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
129 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YM30V00001F1 | [1] | VALVE ASSY, CONTROL (STANDARD) (SEE C.P.M) | VALVE ASSY, CONTROL (STANDARD) (SEE C.P.M) |
| . . | YM30V00001F2 | [1] | CONTROL VALVE | KOBASSY, (NIBBLER& BREAKER) (SEE C.P.M) |
| . . | YM64H00001F1 | [1] | VALVE INSTALLATION | |
| 1. | YM64H01007P1 | [1] | BRACKET | |
| 2. | YM64H01005P1 | [1] | BRACKET | |
| 3. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 4. | ZS18C12060 | [3] | SCREW,Hex, M12 x 60mm | KOBM12x1.75x60mm |
| 5. | ZW16H12000 | [10] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 6. | ZN18C12010 | [3] | NUT | KOBM12x1.75mm |
| 7. | PV02B01073D1 | [2] | CAP | KOB08.4mm Plastic |
