凯斯零件查询(FLX3330B) - FLOATER (12/99-9/02) (02-024) - FUEL TRANSFER PUMP (FLX3300B CASE ENGINE) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
989 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
237-8008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 8, 90 Duro
|
CAS
Superseded by part number: 86637737
|
| 3. |
311184A1
|
[2] |
PLUG
|
CAS
7/8- 16 Or
|
| 4. |
237-8010
|
[1] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 8, 90 Duro
|
CAS
Superseded by part number: 86637738
|
| 7. |
J944823
|
[1] |
ADAPTER
|
CAS
Superseded by part number: 247523
|
| 9. |
233426A1
|
[2] |
PLUG,M10 x 1 ORB
|
CAS
|
| 10. |
84432614
|
[1] |
O-RING,1.6mm Thk x 8.1mm ID, Cl 6, 90 Duro
|
FAR
|
| 11. |
J944386
|
[1] |
FEED PUMP
|
CAS
Assembly Superseded by part number: 87585287
|
| 12. |
9804261
|
[3] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 14. |
J943599
|
[1] |
FUEL TUBE,8 mm OD
|
CAS
|
| 15. |
J903035
|
[2] |
BANJO BOLT
|
CAS
M12 X 24
|
| 16. |
J918191
|
[4] |
PACKING RING
|
CAS
Washer, 12 X 18 X 1 MM Superseded by part number: 87415913
|
| 19. |
J678921
|
[1] |
PLUG
|
CAS
Hex Socket, 14 MM
|
| 20. |
J678912
|
[1] |
O-RING,2.2mm Thk x 11.3mm ID
|
CAS
|
