神钢零件查询(SK160LC) - DYNAMIC ACERA EXCAVATOR 11/2000 ASN YM02U0101 (11/00-12/02) (01-025) - CONTROL BOX ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
883 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M00044F1 | [1] | CONTROL | KOB |
| 1. | YN03M01350F1 | [1] | CONTROL | KOBBOX |
| 1-1. | YN03M01349P1 | [1] | CONTROL | KOBBOX Superseded by part number: YN03M01350F1 |
| 1-2. | 2405R312D1612 | [1] | BUSHING | KOBID 16 x OD 18 x 12mm Long Superseded by part number: 2405U101D1612 |
| 1-3. | 2405R312D2010 | [1] | BUSHING | KOBID 20 x OD 23 x 10mm Long |
| 2. | YN03M01325F1 | [1] | CONTROL UNIT | KOB |
| 3. | YN03M01336P1 | [1] | LEVER | KOB |
| 3-1. | YN03M01336P1001 | [1] | LEVER | KOB Superseded by part number: YN03M01336P1 |
| 3-2. | YN03M01336P1002 | [1] | LEVER | KOBGRIP Superseded by part number: YN03M01336P1 |
| 4. | YN03M01297P1 | [1] | SHAFT | KOB |
| 5. | YN03M01339P1 | [1] | ROD | KOB |
| 6. | YN03M01366P1 | [1] | PLATE | KOB |
| 7. | YN03M01347P1 | [1] | ROLLER | KOB |
| 8. | YN03M01333P1 | [1] | YOKE | KOB |
| 9. | YN03M01352P1 | [1] | PLATE | KOB |
| 10. | YT03M01117P1 | [2] | RUBBER | KOB |
| 11. | YT03M01105F1 | [1] | LOCK ASSY | KOB |
| 11-1. | YT03M01104P1 | [1] | LOCK | KOB Superseded by part number: YT03M01105F1 |
| 11-2. | 2405R312D1415 | [2] | BUSHING | KOB Superseded by part number: 2405R61D5 |
| 12. | PH03M01017P1 | [1] | SPRING | KOB |
| 13. | PY06C01040P1 | [1] | STOP | KOB |
| 14. | YN50S01001P1 | [1] | SWITCH | KOB(Used for Lever Lock, Safety) Superseded by part number: YN50S01001P2 |
| 15. | ZP45X06020 | [1] | PIN | KOBOD 06 x 20mm Long |
| 16. | ZR36X00500 | [1] | SNAP RING | KOBE-Ring -- Shaft 05mm x OD 11mm Superseded by part number: 800-436 |
| 17. | ZR36X00700 | [1] | RING | KOBE-Ring -- Shaft 07mm x OD 14mm |
| 18. | ZR36X01200 | [1] | RING | KOBE-Ring -- Shaft 12mm x OD 23mm |
| 19. | ZR16X01600 | [1] | SNAP RING | KOBRetaining -- ID 14.7 x OD 16 x Th 1.0mm |
| 20. | ZS31C04045 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 45mm | KOB |
| 21. | ZM66C06025 | [2] | BOLT | KOBM06x1.0x25mm (Incls. Washer & Lockwasher) |
| 22. | ZM12C08020 | [1] | BOLT | KOBM08x1.25x20mm (Incls. Lockwasher) |
| 23. | ZM27C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) |
| 24. | ZW16K04000 | [4] | WASHER | KOBID 04 x OD 08 x Th 0.8mm |
| 25. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 26. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 27. | ZW16X16000 | [1] | WASHER | KOBID 16 x OD 30 x Th 3.2mm |
| 28. | ZW16H08000 | [1] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 29. | ZW26X04000 | [2] | LOCK WASHER | KOBID 04 x OD 7.6 x Th 1.0mm |
| 30. | ZN18F10008 | [1] | NUT | KOBM10x1.25mm |
| 31. | ZN18C04003 | [2] | NUT | KOBM04x0.7mm |
| 32. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 34. | ZP16K01616 | [1] | COTTER PIN | KOBOD 1.6 x 16mm Long |
| 35. | ZW16X20000 | [1] | WASHER | KOBID 20 x OD 37 x Th 3.2mm |
| 36. | ZR16X02000 | [1] | RING | KOBRetaining -- ID 18.5 x OD 20 x Th 1.2mm |
