凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (04-011) - TANK/WALKWAY GROUP, CS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
459 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86986843
|
[3] |
MOUNTING PLATE
|
BN
Walkway
|
| 2. |
344215A1
|
[1] |
SUPPORT
|
BN
Lower Tank
|
| 3. |
87266587
|
[3] |
PAD
|
BN
Fuel Tank
|
| 4. |
87266588
|
[3] |
PAD
|
BN
Fuel Tank
|
| 5. |
86625255
|
[36] |
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
|
GI
|
| 6. |
100038
|
[18] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 7. |
86629541
|
[15] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 8. |
9706702
|
[3] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
NH
|
| 9. |
86625252
|
[12] |
WASHER,10.8mm ID x 21.5mm OD x 2.5mm Thk
|
FAR
|
| 10. |
11106231
|
[12] |
BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9
|
LEC
|
| 11. |
BN54039
|
[1] |
ADHESIVE
|
BN
Spray 18 oz
|
