| 1. |
87265530
|
[1] |
TOOL BOX
|
BN
Front, CS
|
| 2. |
87267028
|
[1] |
PLATE
|
BN
Top Fuel Tank
|
| 3. |
87265535
|
[1] |
MOUNTING PLATE
|
BN
Battery Box
|
| 4. |
87268834
|
[1] |
LATCH
|
BN
Battery Box
|
| 5. |
343356A1
|
[1] |
BRACKET, SUPPORTING
|
BN
Mount, Pin
|
| 6. |
728-16100
|
[1] |
CLEVIS PIN,M16 x 100
|
CAS
Superseded by part number: 84078725
|
| 7. |
BN1630425
|
[1] |
PIN, SPLIT (COTTER)
|
BN
PIN, COTTER 1/8 X 1
|
| 8. |
87265547
|
[1] |
ROD
|
BN
Door Stop
|
| 9. |
87266040
|
[2] |
WALKWAY
|
BN
CATWALK Safety, Deck Plate
|
| 10. |
87266041
|
[1] |
WALKWAY
|
BN
CATWALK Safety, Deck Plate
|
| 11. |
87266042
|
[1] |
WALKWAY
|
BN
CATWALK Safety, Deck Plate
|
| 12. |
87268832
|
[1] |
MOUNTING PLATE
|
BN
Door Support
|
| 13. |
86980407
|
[1] |
BOLT,Hex, M10 x 70mm, Cl 8.8
|
BN
M10-1.5 X 70, 8.8, DOR
|
| 14. |
87268827
|
[1] |
ROLLER
|
BN
Plastic
|
| 16. |
87266691
|
[1] |
MOUNTING PLATE
|
BN
Battery Cables
|
| 17. |
87266589
|
[1] |
FOAM
|
BN
Battery Cable, Plate
|
| 18. |
87266592
|
[1] |
SUPPORT
|
BN
Rod
|
| 19. |
87529312
|
[28] |
WASHER,11mm ID x 24mm OD x 3mm Thk
|
BN
|
| 20. |
86980515
|
[14] |
NUT,Hex, M10 x 1.5, Cl 8.8, DOR
|
GI
Superseded by part number: 100037
|
| 23. |
86980432
|
[2] |
BOLT,Hex, M12 x 120mm, Cl 8.8
|
BN
M12-1.75 X 120, 8.8, DOR
|
| 24. |
86981496
|
[4] |
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
|
GI
|
| 25. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 27. |
87529315
|
[8] |
WASHER,9mm ID x 17mm OD x 2mm Thk
|
BN
9 x 17 x 2 mm, HDN, DOR
|
| 30. |
BN50146
|
[12] |
WASHER,3/8", Stainless
|
BN
|
| 31. |
BN322388
|
[12] |
SCREW,Hex, M10 x 1.5 x 30mm, SST
|
BN
M10-1.5 X 30, HH, SS
|
| 32. |
87342591
|
[4] |
BOLT
|
BN
Hex, 1/4"-20 x 1 1/2", G5, Full Thd
|
| 33. |
87343957
|
[4] |
NUT,1/4" - 20
|
BN
Hex, 1/4"-20, GB
|
| 35. |
9991588
|
[2] |
NUT,M8 x 1.25, Cl 8
|
ZED
Superseded by part number: 43442
|
| 36. |
86980401
|
[10] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
BN
|
| 37. |
86980380
|
[2] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd
|
BN
|
| 38. |
86980400
|
[2] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
BU
|
| 39. |
BN71006
|
[2] |
COTTER PIN
|
BN
1/8", #11
|
| 40. |
87266692
|
[3] |
PIPE CLAMP
|
BN
Dual, 16MM
|
| 41. |
BN311653
|
[3] |
PLATE
|
BN
Top, Dual, Size 2
|
| 42. |
86980383
|
[3] |
BOLT,Hex, M8 x 40mm, Cl 8.8
|
BN
|
| 43. |
86986835
|
[2] |
TUBE,12.10 mm ID x 20.40 mm OD x 78 mm L
|
BN
Side Front
|
| 44. |
87344209
|
[1] |
NUT,M10 x 1.5, Cl 10, DOR
|
BN
|
| 45. |
BN30670
|
[1] |
SPRING
|
BN
Spring-3/8" OD X 2" (304 SS)
|
| 46. |
342650A1
|
[1] |
BUMPER
|
BN
Rubber
|
| 47. |
87343666
|
[2] |
NUT
|
BN
Hex, 1/2"-13, G5
|
| 48. |
86981677
|
[1] |
WASHER,11mm ID x 30mm OD x 2.5mm Thk
|
NH
|
