神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (03-005) - BOOM HYDRAULIC LINES 5.2M (17ft 1in) (EXTRA) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
943 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM42H00046F1 | [1] | LINE | KOBHYD LINES, BOOM (EXTRA) |
| 1. | YM42H01159P1 | [1] | TUBE | |
| 2. | YM42H01160P1 | [1] | TUBE | |
| 3. | YM42H01161P1 | [2] | TUBE | |
| 4. | 2444R950D16 | [2] | HOSE | KOB |
| 5. | 2432T3993 | [12] | CLAMP | KOBDouble Line -- 95x38x19mm Hole Only |
| 6. | 2432T3994 | [12] | CLAMP | KOBDouble Line -- 95x38x19mm Threaded M12 |
| 7. | ZA23B18000 | [2] | HYD CONNECTOR | KOB |
| 8. | ZS18C12040 | [12] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| 9. | ZW26X12000 | [12] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 10. | 2414Z199D050 | [2] | PROTECTIVE SLEEVE | KOBHose -- 500mm Long (19-11/16 in) |
