凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (04-021) - BAFFLE GROUP, SIDE RADIATOR Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
579 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN325776
|
[2] |
SEAL
|
BN
Foam, Lower Side
|
| 3. |
F43117X
|
[2] |
SEAL
|
CAS
formed rubber, adhesive-backed, bulk, 15 (9/16) x 31 (1-3/16) x 30480 mm (1200 inch) long
|
| 4. |
120100
|
[14] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 5. |
86588450
|
[28] |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
|
ZED
|
| 6. |
353308
|
[14] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 7. |
87268821
|
[2] |
PLATE
|
BN
RAD Seal
|
| 9. |
343569A1
|
[1] |
PLATE
|
BN
RAD Seal, Top
|
| 10. |
87268819
|
[1] |
FOAM
|
BN
CS
|
| 11. |
87268820
|
[1] |
FOAM
|
BN
RS
|
| 12. |
BN54039
|
[1] |
ADHESIVE
|
BN
Spray 18 oz
|
