| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY30V00008F1 | [1] | VALVE | KOBVALVE, CONTROL EXTRA ROTATION |
| 1. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 2. | 2436R378S1 | [2] | CAP | KOB Superseded by part number: 2436U880S6 |
| 3. | 2436U424S9 | [2] | NUT | KOBM10x1.50mm |
| 4. | 2436U880S8 | [1] | TIE-ROD | KOB |
| 5. | YR20V00001F1 | [1] | VALVE | KOB |
| 6. | 2436R329F1 | [1] | OUTLET | KOB |
| 8. | YT30V00027F1 | [1] | SPOOL | KOB |
| 9. | 2436R1119F5 | [1] | VALVE | KOBASSY, RELIEF |
| 10. | YT22V00006F3 | [2] | VALVE | KOB |
| 11. | YR30V00014S010 | [4] | PLUG | KOB |
| 12. | 2436U2937S18 | [2] | PLUG | KOB |
