神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (07-018) - VALVE ASSY, SOLENOID, P/N LC35V00004F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
386 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC35V00004F2 | [1] | SOLENOID VALVE | KOB |
| 2. | 2436U2802S3 | [2] | SPRING | KOB |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 7. | LC35V00004S007 | [3] | PLUG | KOB1/4" PF |
| 8. | LC35V00004S008 | [4] | SCREW | KOBM05x0.8x10mm |
| 10. | ZD11P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20.6mm |
| 11. | ZD12P01100 | [3] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 12. | NSS | [2] | NOT SOLD SEPARAT | CONSPOOL |
| 13. | YR35V00009S022 | [2] | SOLENOID VALVE | KOB |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 15. | YN30V00080S023 | [2] | SCREW | KOB#2x4.8mm |
