神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (07-027) - GEAR ASSY, PTO Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
965 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YB46W00001F1 | [1] | CASE | KOBGEAR ASSY. (Use oring ZD12G09500 at attach point) Superseded by part number: YB46W00001F2 |
| 115. | NSS | [1] | NOT SOLD SEPARAT | CONSHAT, IDLER |
| 117. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR 2" |
| 118. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR 3" |
| 125. | NSS | [2] | NOT SOLD SEPARAT | CONBEARING, BALL |
| 126. | NSS | [1] | NOT SOLD SEPARAT | CONBEARING, ROLLER |
| 128. | NSS | [2] | NOT SOLD SEPARAT | CONSPACER BEARING |
| 262. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER |
| 326. | NSS | [1] | NOT SOLD SEPARAT | CONCASE, GEAR |
| 414. | ZS23C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
| 435. | YX46W00001S435 | [4] | SOCKET | KOB |
| 468. | 2441U436S469 | [1] | PLUG | KOB |
| 711. | ZD12G08500 | [1] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOBID 84.40 ± 0.73 x OD 90mm |
| 728. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 825. | NSS | [1] | NOT SOLD SEPARAT | CONRING, RETAINING |
| 826. | NSS | [1] | NOT SOLD SEPARAT | CONRING, RETAINING |
| 827. | NSS | [1] | NOT SOLD SEPARAT | CONRING, RETAINING |
| 886. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
