神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (07-028[01]) - VALVE, MAIN CONTROL (YM30V00006F1), FIGURE 1 OF 4 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
792 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30V00006F1 | [1] | CONTROL VALVE | KOBAssembly -- Figure 1 of 4 |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBody |
| 102. | NSS | [2] | NOT SOLD SEPARAT | CONBody |
| 154. | YN30V00001S154 | [1] | PLUG | KOB |
| 155. | YW30V00001S155 | [2] | PLUG | KOB1/2" |
| 156. | YN30V00001S156 | [3] | PLUG | KOB Superseded by part number: YW30V00001S156 |
| 158. | YN30V00001S158 | [1] | PLUG | KOB |
| 162. | ZD12G03000 | [17] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 164. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 166. | ZD12P01400 | [3] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 168. | ZD12P00800 | [1] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 214. | YX20V01001S214 | [1] | PLATE | KOB Superseded by part number: YX30V00002S214 |
| 273. | ZS23C08025 | [40] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 512. | 2436U1265S511 | [11] | POPPET | KOB |
| 522. | 2436U1265S521 | [13] | SPRING | KOB |
| 552. | YN30V00001S552 | [14] | PLUG | KOB Superseded by part number: YN30V00021S552 |
| 562. | ZD12P02000 | [16] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 973. | ZS23C14110 | [7] | SET SCREW,Hex Socket Head, M14 x 110mm | KOBM14x2.0x110mm |
| 974. | ZS23C14075 | [1] | CAPSCREW,Hex Socket Head, M14 x 75mm | KOBSCREW M14x2.0x75mm |
| 977. | NA | [1] | NOT SERVICED | FORName Plate |
| 978. | NA | [1] | NOT SERVICED | FORPin |
