| . . | YM30V00006F1 | [1] | CONTROL VALVE | KOBAssembly -- Figure 3 of 4 |
| 162. | ZD12G03000 | [17] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 163. | ZD12P01500 | [3] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 201. | 2436U1265S201 | [7] | COVER | KOB Superseded by part number: 2436U2631S201 |
| 202. | LP30V01003F1 | [1] | COVER | KOB |
| 204. | YN30V00021S207 | [4] | COVER | KOB |
| 206. | 2436U1265S203 | [8] | COVER | KOB |
| 262. | YY30V00031S262 | [12] | O-RING | KOB Superseded by part number: 2436U1457S162 |
| 265. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 303. | YM30V00007S303 | [1] | SPOOL | KOB |
| 306. | YW30V00006S306 | [2] | Spool | |
| 308. | YM30V00005S308 | [1] | Spool | |
| 309. | YM30V00007S309 | [2] | SPOOL | KOB |
| 310. | YM30V00007S310 | [1] | SPOOL | KOB Superseded by part number: YM30V00005R190 |
| 321. | YN30V00079S325 | [5] | SPRING | KOB |
| 324. | YM30V00007S324 | [4] | SPRING | KOB |
| 325. | YN30V00001S325 | [2] | SPRING | KOB |
| 326. | YN30V00079S326 | [5] | SPRING | KOB |
| 327. | YN30V00001S327 | [2] | SPRING | KOB |
| 329. | YM30V00007S329 | [4] | SPRING | KOB |
| 332. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 333. | 2436U1265S336 | [12] | BOLT | KOB |
| 337. | 2436U1265S335 | [10] | STOP | KOB |
| 338. | YN30V00001S338 | [2] | STOP | KOB |
| 512. | 2436U1265S511 | [11] | POPPET | KOB |
| 522. | 2436U1265S521 | [13] | SPRING | KOB |
| 552. | YN30V00001S552 | [14] | PLUG | KOB Superseded by part number: YN30V00021S552 |
| 562. | ZD12P02000 | [16] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 603. | YN22V00002F9 | [3] | VALVE | KOBAssembly -- See Figure 07-029-04 |
| K. | YM30V00006R120 | [1] | SPOOL | KOBKit, Contains Items 303, 324, 329, 332, 333 & 337 |
| K. | YW30V00006R130 | [1] | SPOOL | KOBContains Items 306, 325, 327, 332, 333 & 338 |
| K. | YM30V00005R170 | [1] | SPOOL | KOBKit, Contains Items 308, 321, 326, 332, 333 & 337 |
| K. | YM30V00005R180 | [1] | SPOOL | KOBKit, Contains Items 309, 321, 326, 332, 333 & 337 |
| K. | YM30V00005R190 | [1] | SPOOL | KOBKit, Contains Items 310, 321, 326, 332, 333 & 337 |
