神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (07-028[04]) - VALVE, MAIN CONTROL (YM30V00006F1), FIGURE 4 OF 4 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
483 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM30V00006F1 | [1] | CONTROL VALVE | KOBAssembly -- Figure 4 of 4 |
| 156. | YN30V00001S156 | [3] | PLUG | KOB Superseded by part number: YW30V00001S156 |
| 162. | ZD12G03000 | [17] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 166. | ZD12P01400 | [3] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 201. | 2436U1265S201 | [7] | COVER | KOB Superseded by part number: 2436U2631S201 |
| 206. | 2436U1265S203 | [8] | COVER | KOB |
| 213. | YN30V00079S213 | [1] | PLATE | KOB |
| 217. | YN30V00075F1 | [1] | VALVE | KOBAssembly -- See Figure 07-029 |
| 262. | YY30V00031S262 | [12] | O-RING | KOB Superseded by part number: 2436U1457S162 |
| 265. | ZD12G03500 | [8] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 272. | ZS23C12035 | [4] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 274. | ZS23C12090 | [4] | CAPSCREW,Hex Socket Head, M12 x 90mm | KOBSCREW M12x1.75x90mm |
| 304. | YM30V00007S304 | [1] | SPOOL | KOB |
| 305. | YM30V00007S305 | [1] | SPOOL | KOB Superseded by part number: YM30V00005R140 |
| 321. | YN30V00079S325 | [5] | SPRING | KOB |
| 324. | YM30V00007S324 | [4] | SPRING | KOB |
| 326. | YN30V00079S326 | [5] | SPRING | KOB |
| 329. | YM30V00007S329 | [4] | SPRING | KOB |
| 332. | 2436U1265S332 | [24] | SPRING SEAT | KOB |
| 333. | 2436U1265S336 | [12] | BOLT | KOB |
| 337. | 2436U1265S335 | [10] | STOP | KOB |
| 512. | 2436U1265S511 | [11] | POPPET | KOB |
| 522. | 2436U1265S521 | [13] | SPRING | KOB |
| 552. | YN30V00001S552 | [14] | PLUG | KOB Superseded by part number: YN30V00021S552 |
| 562. | ZD12P02000 | [16] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 602. | YN22V00002F1 | [3] | VALVE | KOBAssembly -- See Figure 07-029-01 |
| 603. | YN22V00002F9 | [3] | VALVE | KOBAssembly -- See Figure 07-029-04 |
| K. | YM30V00005R130 | [1] | SPOOL | KOBKit, Contains Items 304, 324, 329, 332, 333 & 337 |
| K. | YM30V00005R140 | [1] | SPOOL | KOBKit, Contains Items 305, 321, 326, 332, 333 & 337 |
