神钢零件查询(SK160LC-6E) - DYNAMIC ACERA EXCAVATOR 08/2004 ASN YM03U0523 (8/04-12/07) (09-013 ) - TIMING GEAR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
617 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 02003A. | VAME212179 | [1] | CASE ASSY, TIMING GEAR | |
| 02034B. | VAME017112 | [2] | POINTER | KOBTIMING GEAR CASE |
| 2036. | VAME017208 | [1] | OIL SEAL | KOBTIMING GEAR CASE |
| 2982. | VAMF472406 | [1] | PIN | KOBTIMING POWER TRAIN CASE, DOWEL,12X24 |
| 2992. | VAMS666136 | [1] | PLUG | KOBCAP, TIMING GEAR CASE, D = 22 |
| 02993B. | VAMH001403 | [2] | BOLT, TIMING GEAR CASEFLANGE. 8X100 | |
| 02993C. | VAMF140240 | [4] | BOLT | KOBTIMING GEAR CASE,FLANGE,8X75 |
| 02993D. | VAMF140241 | [7] | BOLT | KOBTIMING GEAR CASE,FLANGE,8X80 |
| 02993E. | VAMF140237 | [6] | BOLT | KOBTIMING GEAR CASE,FLANGE,8X60 |
| 3026. | VAME017115 | [1] | GEAR | KOBCRANKSHAFT,N=31 |
| 3033. | VAME017239 | [1] | SLINGER | KOBOIL, CRANKSHAFT, FR |
| 03107B. | VAME013074 | [1] | BUSHING | KOBTIMING GEAR TRAIN |
| 03132A. | VAME013129 | [1] | IDLER GEAR | KOBASSY, CAM ,N=63 |
| 3145. | VAME014385 | [1] | PLATE | KOBCAM IDLER GEAR THRUST Superseded by part number: VAME015107 |
| 03155B. | VAME015106 | [1] | CAMSHAFT | KOBIDLER GEAR |
| 03298E. | VAMF140435 | [2] | BOLT | KOBTIMING GEAR TRAIN,FLANGE,8X50 |
