凯斯零件查询(FLX3510) - FLOATER (8/04-8/06) (02-030) - FAN BELT DRIVE GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
275 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN324094
|
[1] |
SUPPORT
|
BN
Fan Drive
|
| 2. |
BN325124
|
[1] |
Idler Pulley Group
|
|
| 3. |
86639325
|
[12] |
WASHER,10.8mm ID x 24.5mm OD x 3mm Thk
|
FAR
|
| 4. |
86624978
|
[4] |
BOLT,Hex, M10 x 35mm, Cl 10.9, Full Thd
|
ZED
|
| 5. |
100037
|
[4] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 6. |
120073
|
[4] |
BOLT,Hex, M10 x 86.58mm, Cl 8.8
|
NH
Superseded by part number: 129796A1
|
| 7. |
BN325050
|
[1] |
V-BELT,28.00 mm W x 2607.00 mm L
|
BN
Superseded by part number: 84057710
|
