| 1. |
J949093
|
[1] |
FEED PUMP
|
CAS
Assembly - Fuel Transfer
|
| 2. |
J944382
|
[1] |
GASKET
|
CAS
Fuel Pump
|
| 3. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Valve - Check
|
| 5. |
86637929
|
[3] |
BOLT,Hex, 1/4" - 28 x 2", Gr 5
|
RAC
|
| 6. |
J678923
|
[2] |
PLUG,M10 x 1
|
CAS
Hex Socket, 10 MM
|
| 7. |
86625087
|
[1] |
O-RING,1.6mm Thk x 8.1mm ID, Cl 7, 75 Duro
|
FAR
|
| 8. |
J944152
|
[1] |
FLANGE BOLT,Hex, M8 x 1.25 - M10 x 1.5 x 25mm, Cl 8.8
|
CAS
10-1.5 X 8-1.25 MM
|
| 9. |
9804261
|
[2] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 10. |
311214A1
|
[1] |
ADAPTER
|
CAS
7/8-16 45º FL X OR
|
| 11. |
237-8010
|
[1] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 8, 90 Duro
|
CAS
Superseded by part number: 86637738
|
| 12. |
J3062139
|
[1] |
ELBOW
|
CAS
90 Degree, 3/4-16 45 Degree FL X ADJ OR
|
| 13. |
237-8008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 8, 90 Duro
|
CAS
Superseded by part number: 86637737
|
| 14. |
311215A1
|
[1] |
PLUG
|
CAS
3/4-16 OR
|
| 16. |
311184A1
|
[1] |
PLUG
|
CAS
7/8- 16 Or
|
| 19. |
J943599
|
[1] |
FUEL TUBE,8 mm OD
|
CAS
Fuel Drain
|
| 20. |
J903035
|
[2] |
BANJO BOLT
|
CAS
Hex, 12 - 1.5 X 24 MM
|
| 21. |
87415913
|
[4] |
SEALING WASHER,11.71mm ID x 19.3mm OD x 1.27mm Thk
|
CAS
Special, 12 X 19 X 1.5 MM
|
| 22. |
J948229
|
[1] |
FUEL TUBE,0.394" OD
|
CAS
Fuel Drain
|
| 23. |
J924725
|
[2] |
BANJO BOLT,M14 x 1.5 x 26mm
|
CAS
Connector
|
| 24. |
J918192
|
[4] |
PACKING RING,14mm ID x 20mm OD x 1mm Thk
|
CAS
Washer - Sealing, Special, 14 X 20 X 1 MM Superseded by part number: 87417767
|
| 25. |
845-8016
|
[1] |
BOLT,Hvy Hex, M8 x 16mm, Cl 8.8
|
CAS
|
